Appendix 2 Reference
A4
FFT File
File size (bytes) =header size
*1
+ the size of the time axis data
*2
+ the size of the mid-term data
*3
*1: Header size = 30720 + 512(analog channel portion +Number of waveform calculation channels+Number of FFT cal-
culation channels + 1)
*2: the size of the time axis data = (analog channel portion + 2 xNumber of waveform calculation channels) x data (*4)
*3: the size of the mid-term data = (346 x Number of FFT points + 836) x Number of FFT calculation channels(*4)
(Depending on the measurement conditions, the file size may also increase or decrease from calculation formula result)
CSV (Text) File
Memory Function
File size (bytes) = header size
*1
+ data size
*2
*1: Header size = 194 + 103 x (saved analog channels + saved logic channels)
*2: Data size = (18 + 14 x saved analog channels + 2 x logic channels) x number of data
Recorder Function
File size (bytes) = header size
*1
+ data size
*2
*1: Header size = 194 + 130 x (saved analog channels + saved logic channels)
*2: Data size = (18 + 28 x saved analog channels + 4 x logic channels) x number of data
Appendix 2 Reference
A5
Appendix
For information on the size of setting and image data files, see the table below.
Appendix 2.2 Setting Configuration and Image Data
File Sizes
File Size
Setting file 33 KB
BMP (No color compression) 470 KB
BMP (Gray scale/No compression) 470 KB
BMP (B/W/No compression) 59 KB
BMP (B/W Reverse/No compression) 59 KB
Appendix 2 Reference
A6
The maximum available recording time depends on the selected timebase.
The maximum recording time can be obtained by the following formula.
Refer to the following tables for the information about recordable time.
(d: days/ h: hours/ min: minutes/ s: seconds)
Appendix 2.3 Timebase and Maximum Recordable
Time
Recordable time can be verified on the Status
screen - [Status] sheet. ([Recording period])
Recordable Time = Timebase x Recording Length
Setting a slow timebase may result in a very long recording time (over a year)
which may exceed the guarantee period or product life, in which case we cannot
guarantee operation.
Memory Function
Timebase
(Time/div)
Sampling Rate
Maximum Recording
Length
160,000 div
5 s
50 ns 0.8 s
10 s 100 ns 1.6 s
20 s 200 ns 3.2 s
50 s 500 ns 8 s
100 s1 s16 s
200 s2 s32 s
500 s5 s1 min 20 s
1 ms 10 s2 min 40 s
2 ms 20 s5 min 20 s
5 ms 50 s 13 min 20 s
10 ms 100 s 26 min 40 s
20 ms 200 s 53 min 20 s
50 ms 500 s 2h 13 min 20 s
100 ms 1 ms 4 h 26 min 40 s
200 ms 2 ms 8 h 53 min 20 s
500 ms 5 ms 22 h 13 min 20 s
1 s 10 ms 1 d 20 h 26 min 40 s
2 s 20 ms 3 d 16 h 53 min 20 s
5 s 50 ms 9 d 6 h 13 min 20 s
10 s 100 ms 18 d 12 h 26 min 40 s
30 s 300 ms 55 d 13 h 20 min 0 s
50 s 500 ms 92 d 14 h 13 min 20 s
1 min 600 ms 111 d 2 h 40 min 0 s
100 s 1 s 185 d 4 h 26 min 40 s
2 min 1.2 s 222 d 5 h 20 min 0 s
5 min 3 s
