Preface
i
Preface
We sincerely thank you for buying this Chip Mounter (hereinafter referred to as the
“machine”) manufactured by Hanwha Precision Machinery Co., Ltd.
This machine is designed and configured to place electrical/electronic parts picked up
from a feeder on a PCB.
Do not use this machine for uses other than its original use.
Caution [Before operating this machine]
Before operating this machine, please read this manual and understand its contents.
Please keep this manual near the machine at all times so that it can be referred to as
necessary.
Users who have not received training on this machine should not use it.
Hanwha Precision Machinery Co., Ltd. provides a training program for operating this
machine. For details, please contact our SMT Global Training Center and local agent
designated by Hanwha Precision Machinery Co., Ltd.
Fast Flexible Placer SM481(L) PLUS Administrator’s Guide
ii
About Safety
In order to use this machine properly and safely, observe the rules and instructions
regarding safety mentioned in this manual.
Basic items to be observed while using this machine are as follows:
In order to use the machine properly and safely, users must receive appropriate
training.
When performing machine inspection, part replacement, repair or internal setup,
turn off the power switch.
Repairs and maintenance of this machine not mentioned in this manual should
only be performed by a service engineer authorized by Hanwha Precision
Machinery Co., Ltd. No repairs or maintenance should be done by a customer at
their discretion. Otherwise, unexpected accidents may occur.
First, teach the machine after checking for safety around the machine and take
measures against any errors that occurred to the machine while not in its 'READY'
state.
Do not use the machine where inflammable gas is present or contamination is
severe.
Cautions to be exercised for safety are described in this manual as follows:
Danger Indicates an imminently hazardous situation which, if
remarks following this symbol are not observed, will result in
death or serious injury. Therefore, instructions must be
followed without fail.
Warning Indicates a potentially hazardous situation which, if remarks
following this symbol are not observed, will result in death or
serious injury. Therefore, instructions must be followed
without fail.
Caution If remarks following this symbol are not observed, damage
to the machine, embedded program, data, etc. may occur,
or accidents involving personal injury may occur. Therefore,
instructions must be followed without fail.
Preface
iii
Safety Precaution
Following labels described in each section are attached on specific position of this
machine. Follow the instructions on each label for operating this machine safely.
If a label has come off or has damaged, put a new one on a specific position referring to the
following figures. For ordering a new label or offering any comment, questions, please
contact to the business department or the local agent designated by Hanwha Precision
Machinery Co., Ltd.
Front View of the Machine
The following labels are attached on the front part of this machine.
Figurei.1 Safety labels attached on the front part of the machine
Do not open the door during operation.
Part where this label is attached contains
moving parts, it is very dangerous if the user
open the cover while operating.
