Preface

xvii

Warning If power supply is cut off suddenly, it could result in the

damage of data and machine.

And the machine might be damaged due to abnormal

operation when power is supplied again.Before turning off

power, be sure to end the MMI, turn off the main switch,

then turn on the main switch after 5-10 seconds.

 Safeguard override key switch

This is a key switch that can be operated artificially to prevent the door switch from

operating. It should be used limitedly only when performing initial setting or

maintenance of the machine.

Danger The Safeguard override key switch must be used by the

designated responsible personnel. It must be carefully used

for machine operation. Failure to do so may result in death

or serious personal injury if the operator approached the

drive with the safety cover Open.

 Operation Panel (OP Panel)

Consists of Buttons for machine operation and the emergency stop switch.

 STOP Button (Red Color)

This is a Button for temporary stopping of the operation. Automatic operation of

this machine is temporarily stopped if this Button is pressed. If this Button is

pressed while the placement is in progress, the operation is stopped after the

present operation is completed. This Button can also be used for turning off alarm

sound due to an error.

 START Button (Green Color)

This is a switch for initiating the operation of this machine. Automatic operation is

initiated if this switch is pressed.

Warning Pressing the START Button without checking the presence

of worker nearby could cause injury.Be sure to check if

there is any worker near the machine before pressing the

START Button.

 READY Button

This is a switch for initiating the operation of this machine. The power is supplied

Fast Flexible Placer SM481(L) PLUS Administrator’s Guide

xviii

to the driving systems such as motor. It is used to put the machine into the standby

status after power-up. ‘EMG (emergency stop)’ switch can be pressed to release

the standby state.

 RESET Button (Blue Color)

Used to stop production in a machine that has paused automatic production or to

release the error in a machine that has been paused due to an error. Pressing this

Button in a machine to which an error has occurred will change the state of the

machine from 'FREEZE' or 'EMER' to 'IDLE'. The ‘Reset’ Button cannot be

activated during automatic operation of this machine.

 F/R SELECTS Button

It is the Button that determines which one of the front operation panel and rear

operation panel will have the control authority. Whether or not the corresponding

operation panel has the control authority depends on the status of this Button.

When initializing the machine, the front is set to have right for control by default.

(Front side by default.)

If the select Button is pressed and maintained for a second, the LED Button is

turned on and the right for control is transferred to the rear side. It takes 0.3~1

seconds to change the right for control from the front OP panel to the rear OP

panel. The same applies when changing the right for control reversely.

The same applies for the rear side. The following table shows this briefly.

 Feeder change Button

The Button used to replace the feeders on the front and rear feeder base. When this

Button is pressed, the head unit of the machine come to the safety zone for easy

feeder change.

 EMG (Emergency Stop) Switch

This is an emergency stop switch. Operation of this machine is immediately

suspended if this switch is pressed in case of an emergency.

Supply of all powers except for the power to a computer is ceased. The emergency

stop status can be released by turning the ‘EMG’ switch in the direction of the

arrow and pressing the RESET Button.

Right for control

Front panel select

Button LED status

Rear panel select

Button LED status

Front On Off

Rear On Off

Preface

xix

About Warranty

The warranty is issued to cover the following machine faults and malfunctions.

However, the contents of the warranty stipulated at the time of purchase take

precedence over the above coverage.

What is covered by

the warranty

If any part of the machine fails to function properly under normal

conditions of usage due to defects in material or workmanship, it will

be repaired by Hanwha Precision Machinery Co., Ltd. at no charge for

either parts or labor.

Time period of the

warranty

The term of this warranty shall expire for any of the following cases:

 24 months after delivery from the fac

tory

 24 months after installation

What is not

covered by the

warranty

Any of the following cases are not covered by this warranty:

 Data lost due to HDD damage. (Please back up the data

periodically.)

 Malfunction of the system due to the execution of a program

regardless of machine operation, as well as data damage due to

infection by any computer viruses.

 Damage due to due to long-term use or defe

cts due to the wear

arising from normal use (natural fading of coating and plating,

wearing-out of parts, etc.).

 Delicate changes which do not affect the functional quality (such

as noise from a controller, sound of a rotating motor, etc.).

 Defects due to ambient conditions (moisture, impurities, dust on

the machine, oil mist, etc.).

 When failure occurs to the machine due to customer's mistake.

Def

ects resulting from the following cases are also not covered by

this warranty:

 Natural disasters such as earthquake, typhoon, flood and

lightning strike, or accident, fire, etc.

 Modification which was not approved by our company or agents.

 F

ailure to back up the data stored in the machine.

 Use of parts or lubricants other than those designated.

 Insufficient or defective maintenance or inspectio

 Adjustments performed by persons other than designated agents.
