9-2

Fast Flexible Placer SM481(L) PLUS Administrator’s Guide

 <R> column

Set the R position (rotation angle of the placement component) of the placement

position.

 <Part> column

Select the component to place.

 <Description> column

Note that slot to display the description of installed components.

 <FDR> column

Select the feeder to supply the component.

 <NZ> column

Select the nozzle to pick up the component.

 <HD> column

Selects the head to pick up the part to be placed.

 <CS> column

When you want to start a new cycle, check this check box.

 <CY> column

When <Cycle> is clicked on, the corresponding cycle number is displayed.

 <SK> column

Check the check box when you want to skip the placement point. The number of

skipped rows is indicated in the ‘Skipped Count’.

Memo The part set to be skipped is not included in the number of parts that

can be placed. (The maximum number of parts that can be placed is

150.)

Possible to skip the selected lines after selecting the lines to be skipped with the

mouse. On the contrary, it is possible to setup so as not to skip.

1: Selection of drag using mouse

 Select lines using mouse. (Use the mouse drag function.)

9-3

Step Programming

 Popup menu appears by clicking the right side button of the mouse.

 Select “Skip” or “No Skip”.

It is possible to skip a placement point in the Layout screen.

 Part Skip

You can select this function by right clicking the mouse. You can exclude

work on the corresponding placement point by using this function.

 Part Skip Release

You can select this function by right clicking the mouse. Use of this function

will allow the placement point, which is set to be skipped, to be worked on

again.

 <AR> column

Select the array PCB number to which the placement point belongs.

 <FID> column

If the fiducial mark data of the placement point has been set in <Fiducial…>, “Y”

is displayed, if not “N” is displayed.

 <PL> column

Checks the placement point at which placement has already performed. This

equipment provides the function that can select a specific placement point in the

Step dialog box and perform placement at the corresponding point.

If placement is performed by this function, the placement point at which the part

has been placed is automatically check-marked to avoid duplicated placement

when performing placement later.

9-4

Fast Flexible Placer SM481(L) PLUS Administrator’s Guide

 <LV> column

For parts such as Shield Cap parts, which are to be placed after other parts, this

level value is set to a high value so that corresponding parts can be placed after all

parts with a low level have been placed.

 <Teach> group

Used for moving the selected object to the assigned position of coordinates by rotating

XY axis driving motor, or for obtaining the present coordinates of the selected object.

 button

Setup illumination level of fiducial camera to be used for teaching installation

position. Please refer to “8.1.2 Stick Unit” for more information.

 Combo Box

Used for selecting the object to move to the designated coordinates by rotating the

XY axis driving motor or to select the object for which the present coordinates is

searching. Selectable objects are as follows;

 Fid Cam(Option): Selects the fiducial camera of the head.

 Head 1 ~ Head 10: Selects the Head #1~Head #10 of the Front gantry

 <Move> button

Move the object selected in the Combo Box to the position of the assigned

coordinates. At this time, Before executing <Move> button, the cell in the grid

(Coordinates of installation position) corresponding to the desired position must

be clicked on.

 <Get> button

Obtain coordinates for XY axis with reference to the object selected in the Combo

Box. At this time, Before executing <Get> button, the cell in the grid (Coordinates

of installation position) corresponding to the desired position must be clicked on.

 <Use Hot Key> check box

Use the hot key to register and move the placement point.

 F2: Move the previous placement point.

 F3: Move the next placement point.

 F4: Move the placement point.

 F5: Register the placement point.

 <Move> group

Moves the head assembly by driving the shaft of the X and Y driving motors to the

placement point of the previous or following row of the current row.

 <Move Prev> button
