9-3

Step Programming

 Popup menu appears by clicking the right side button of the mouse.

 Select “Skip” or “No Skip”.

It is possible to skip a placement point in the Layout screen.

 Part Skip

You can select this function by right clicking the mouse. You can exclude

work on the corresponding placement point by using this function.

 Part Skip Release

You can select this function by right clicking the mouse. Use of this function

will allow the placement point, which is set to be skipped, to be worked on

again.

 <AR> column

Select the array PCB number to which the placement point belongs.

 <FID> column

If the fiducial mark data of the placement point has been set in <Fiducial…>, “Y”

is displayed, if not “N” is displayed.

 <PL> column

Checks the placement point at which placement has already performed. This

equipment provides the function that can select a specific placement point in the

Step dialog box and perform placement at the corresponding point.

If placement is performed by this function, the placement point at which the part

has been placed is automatically check-marked to avoid duplicated placement

when performing placement later.

9-4

Fast Flexible Placer SM481(L) PLUS Administrator’s Guide

 <LV> column

For parts such as Shield Cap parts, which are to be placed after other parts, this

level value is set to a high value so that corresponding parts can be placed after all

parts with a low level have been placed.

 <Teach> group

Used for moving the selected object to the assigned position of coordinates by rotating

XY axis driving motor, or for obtaining the present coordinates of the selected object.

 button

Setup illumination level of fiducial camera to be used for teaching installation

position. Please refer to “8.1.2 Stick Unit” for more information.

 Combo Box

Used for selecting the object to move to the designated coordinates by rotating the

XY axis driving motor or to select the object for which the present coordinates is

searching. Selectable objects are as follows;

 Fid Cam(Option): Selects the fiducial camera of the head.

 Head 1 ~ Head 10: Selects the Head #1~Head #10 of the Front gantry

 <Move> button

Move the object selected in the Combo Box to the position of the assigned

coordinates. At this time, Before executing <Move> button, the cell in the grid

(Coordinates of installation position) corresponding to the desired position must

be clicked on.

 <Get> button

Obtain coordinates for XY axis with reference to the object selected in the Combo

Box. At this time, Before executing <Get> button, the cell in the grid (Coordinates

of installation position) corresponding to the desired position must be clicked on.

 <Use Hot Key> check box

Use the hot key to register and move the placement point.

 F2: Move the previous placement point.

 F3: Move the next placement point.

 F4: Move the placement point.

 F5: Register the placement point.

 <Move> group

Moves the head assembly by driving the shaft of the X and Y driving motors to the

placement point of the previous or following row of the current row.

 <Move Prev> button

9-5

Step Programming

Moves the head assembly by driving the shaft of the X and Y driving motors to the

placement point of the previous row of the current row.

 <Move Next> button

Moves the head assembly by driving the shaft of the X and Y driving motors to the

placement point of the following row of the current row.

 <Outline> check box

When checking the placement point, it shows pcb pattern image with the virtual

part image in the SMVision window using the Align data.

 <Auto> check box

To move continuously, check this check box. When this check box has been

clicked on and <Move Prev> or <Move Next> is clicked on.

 <Find> group

Set the string of characters to find. At this time, the column in the grid containing the

string of characters must be specified first.

 <Find Prev> button

Finds the string of characters set in the edit box in the previous lines of the current

line of the column specified in the grid.

 <Find Next> button

Finds the string of characters set in the edit box in the next lines of the current line

of the column specified in the grid.

 <Array> group

 <Block> combo box

For block PCB, first select the block to set. Then set other items.

Click the button to select the block to set. If it is not a block PCB, it is not

necessary to select the block and the corresponding Combo Box is disabled.

 <Array No.> combo box

Selects an array among the arrays for which placement point is to be indicated.

 <Extend> check box

Displayed only in the case of Array PCB. Expand the placement point to one PCB

by using the offset value of array PCB.

For example, if the number of current placement points is 10 and the number of

array PCB is 4, then the total number of placement points is expanded to 40.

If it is already expanded, returns to the original status. At this time, all placement

data disappear except for no. 1 array PCB.
