Preface vii Figurei.4 Safety labels attached on the inside of the machine at the rear Do not touch the head assembly . Be careful of electric s hoc k. T urn of f the main switch before performing maintenance since fata l…
Fast Flexible Placer SM481(L) PLUS Administrator’s Guide
vi
Internal Part of the Machine.
The following labels are attached on the rear part of this machine.
Figurei.3 Safety labels attached to the inside of the machine at the front
Do not put a hand in during operation.
Part where this label is attached contains
moving parts, it is very dangerous if the user
disassembles any part or opens the cover
while operating.
Stop the machine before servicing.
Stop the machine before maintenance or
error troubleshooting.
Do not modify the door key.
Unauthorized modification of the door key is
prohibited. It may be dangerous.
Name Plate
(Mach
ine Name Plate)
Describes the model name, serial number
and basic specifications of the machine.
Check the pneumatic pressure and voltage
specified in the name plate and operate the
machine in compliance with the
specifications.
Preface
vii
Figurei.4 Safety labels attached on the inside of the machine at the rear
Do not touch the head assembly.
Be careful of electric shock.
Turn off the main switch before performing
maintenance since fatal personnel injury
may occur. Be careful of the residual
current.
Fast Flexible Placer SM481(L) PLUS Administrator’s Guide
viii
Do not remove safety function. It may cause
serious injuries and troubles.
Check before service.
Remove power & air-source only for
authorized personnel.
