and of a thickness when cured not greater than 0.13 mm [0.005 in] total, using the prepreg manufacturer’s recom- mended press cycle. Laminate over 0.5 mm [0.020 in] shall be treated like double clad laminate without lami…

1.0

Scope

This

method is designed to evaluate the resis-

tance of dielectric materials to organic chemicals representa-

tive of those used in printed board fabrication and assembly.

It is intended to provide a distinction between materials of

varying chemical resistance and, when applicable, an indica-

tion of the degree of cure.

2.0

Applicable Documents

IPC-TM-650

Method

2.2.18, Determination of Thickness of Laminates by

Mechanical Measurement

Weast, R.C., CRC Handbook of Chemistry and Physics, 65th

Edition, E-37, 1984

3.0

Test Specimens

3.1 Number

Unless

otherwise specified, three specimens

shall be used.

3.2

Size

Unless

otherwise specified, specimen shall be

50.8 x 50.8 mm ± 0.5 mm [2.0 x 2.0 ± 0.02 in] by the thick-

ness of the material (see 5.1, Preparation). Edges shall be

smooth, whether by the cutting procedure, or by sanding, or

other means.

3.3

Location

Specimen

may be cut from anywhere in the

sheet of material, except no specimens shall be taken closer

than 25.4 mm [1.0 in] from any edge as laminated.

4.0

Apparatus or Material

4.1

Analytical

balance with a draft shield and .001 gram or

better resolution.

4.2

Air

circulating oven, capable of 105 ± 2°C [221 ± 3.6°F].

4.3

Desiccator

capable of maintaining an atmosphere of less

than 30% relative humidity at 23°C [73°F]. See 6.2.5

4.4

Cutting

apparatus such as diamond saw, shear paper

cutter or router.

4.5 Edge

smoothing apparatus such as 400 grit or finer

sandpaper.

4.6

One

liter battery jar, with cover.

4.7 Metal tongs or forceps.

4.8

Metal

rack (to support specimens vertically).

4.9

Metal

support (e.g., mounting clip used for microsec-

tioning).

4.10

Laminating

press capable of the specified temperature

and pressure.

4.11

Timer:

1 hour with 1 second resolution.

4.12

Timer:

60 seconds, 1 second resolution.

4.13

Solvent:

Methylene Chloride, Reagent Grade or HPLC

Grade. MC recovered by distillation back to reagent grade

may be used. HPLC Grade shall be used for referee pur-

poses.

4.14

Prepreg

(for single sided laminate and coated foil test

only).

4.15 Copper

foil, 1 oz./ft

treated

(for prepreg tests only).

4.16

Ventilation

hood

4.17 Micrometer,

capable of measuring to within 0.025 mm

[0.001 in]

4.18

Water

bath at 23 ± 0.5°C [73 ± 0.9°F].

4.19

Thermometer

capable of measuring to within 0.1°C

resolution.

4.20

Etching

system capable of metallic cladding removal.

5.0

Procedure

5.1 Sample Preparation

5.1.1 Single-sided Laminate

Single-sided

laminate less

than 0.5 mm [0.020 in] shall be laminated together with the

clad surfaces facing out. Two plies minimum of prepreg shall

be used. The prepreg shall be of the same basic resin type

The

Institute for Interconnecting and Packaging Electronic Circuits

2215 Sanders Road • Northbrook, IL 60062-6135

IPC-TM-650

TEST

METHODS MANUAL

Number

2.3.4.2

Subject

Chemical

Resistance of Laminates, Prepreg, and

Coated Foil Products, by Solvent Exposure

Date

12/94

Revision

Originating Task Group

MIL-P-13949 Test Methods Task Group (7-11b)

Material

in this Test Methods Manual was voluntarily established by Technical Committees of the IPC. This material is advisory only

and its use or adaptation is entirely voluntary. IPC disclaims all liability of any kind as to the use, application, or adaptation of this

material. Users are also wholly responsible for protecting themselves against all claims or liabilities for patent infringement.

Equipment referenced is for the convenience of the user and does not imply endorsement by the IPC.

age1of4
