1 Scope This test is a method for determining acid accep- tance of chlorinated solvents. Acid acceptance is applicable for evaluating the condition of the following inhibited chlorinated solvents. • Perchloroethylene • 1…

6.1.4

glassware is used during testing, it is recommended

that it should be cleaned thoroughly prior to use to eliminate

the possibility of interfering contaminants.

6.2

Safety

Observe

all appropriate precautions on MSDS

for chemicals involved in this test method.

IPC-TM-650

Number

2.3.35.2

Subject

Fluoride

Concentration, Fluxes-Quantitative

Date

06/04

Revision

age3of3

电子技术应用　　　　　　　ｗｗｗ．ＣｈｉｎａＡＥＴ．ｃｏｍ

Scope

This

test is a method for determining acid accep-

tance of chlorinated solvents.

Acid acceptance is applicable for evaluating the condition of

the following inhibited chlorinated solvents.

• Perchloroethylene

• 1,1,1-Trichloroethane

• Methylene Chloride

• Trichloroethylene

Applicable Documents

ASTM D2111-95

Standard

Test Methods for Specific Gravity

of Halogenated Organic Solvents and Their Admixtures

Test Specimen

3.1

ml of solvent (see 5.1 for sampling procedure)

Apparatus

4.1

One

flask, Erlenmeyer, 100 ml, with glass stoppers (see

6.5)

4.2

Two

flasks, Erlenmeyer, 250 ml, with glass stoppers (see

6.5)

4.3

Two

flasks, Volumetric, 1000 ml, with glass stoppers

(see 6.5)

4.4

Two

pipets, 25 ml, with bulb (see 6.5)

4.5

One

pipet, graduated (calibrated), with bulb (see 6.5)

4.6 One

eye dropper (see 6.5)

4.7

One

balance, analytical (see 6.5)

4.8

Two

pieces of weighing paper (see 6.5)

4.9

Sodium

hydroxide 0.1 N in C.P. anhydrous methanol

(5.2.1 & 6.5)

4.10

Hydrochlorination

reagent, 0.1 N Hydrochloric acid in

anhydrous isopropanol (see 5.2.2 & 6.5)

4.11

Bromothymol

blue indicator, 0.1% solution

Note: Make sure all glassware is clean and dry.

Procedure

5.1 Sampling Procedure

5.1.1

Securely

tie a copper wire around the neck of a 100 ml

Erlenmeyer flask. Carefully lower, allow to fill, stopper, and

store in cool, dark place.

5.1.2

Since

a representative sample is desired, sampling

should be done when the tank is half full. Most tanks (or hoses

from them) have sampling points. From here, fill a 100 ml

Erlenmeyer flask, stopper, and store in a cool, dark place.

5.1.3

See

6.3 for safety and handling and 6.4 for first aid.

5.2

Reagent Preparation

5.2.1 Sodium Hydroxide Solution Preparation

5.2.1.1

Weigh

4.0 g reagent grade NaOH.

5.2.1.2

Pour

approximately 500 ml C.P. anhydrous metha-

nol into a 1 liter volumetric flask.

5.2.1.3

Add

NaOH and swirl until dissolved.

5.2.1.4

Dilute

solution to exactly 1 liter with methanol and

stopper. See 6.3 for safety and handling information and 6.4

for first aid information.

5.2.2

Hydrochlorination Reagent Preparation

5.2.2.1

Pour

about 500 ml anhydrous isopropanol into an 1

liter volumetric flask.

5.2.2.2

Bulb

pipet exactly 8.50 ml 37% HCl into the flask,

then swirl.

The

Institute for Interconnecting and Packaging Electronic Circuits

2215 Sanders Road • Northbrook, IL 60062-6135

IPC-TM-650

TEST

METHODS MANUAL

Number

2.3.36

Subject

Acid

Acceptance of Chlorinated Solvents

Date

10/85

Revision

Originating Task Group

N/A

Material

in this Test Methods Manual was voluntarily established by Technical Committees of the IPC. This material is advisory only

and its use or adaptation is entirely voluntary. IPC disclaims all liability of any kind as to the use, application, or adaptation of this

material. Users are also wholly responsible for protecting themselves against all claims or liabilities for patent infringement.

Equipment referenced is for the convenience of the user and does not imply endorsement by the IPC.

age1of3

电子技术应用　　　　　　　ｗｗｗ．ＣｈｉｎａＡＥＴ．ｃｏｍ

5.2.2.3

Dilute

solution to exactly 1 liter and stopper. See 6.3

for safety and handling information and 6.4 for first aid infor-

mation.

5.3

Test Procedure

5.3.1

Measure specific gravity of sample using ASTM

Method D 2111-95.

5.3.2

Bulb

pipet exactly 25 ml sample into a 250 ml Erlen-

meyer flask.

5.3.3 Bulb

pipet exactly 25 ml hydrochlorination reagent into

sample, stopper, then mix thoroughly.

5.3.4

Let

sit 15 to 20 minutes for complete reaction. During

reaction time, a blank may be run (see 5.3).

5.3.5

When

reaction time is complete, add five drops of bro-

mothymol blue 0.1% solution with an eye dropper.

5.3.6

Titrate

the sample to endpoint with 0.1 N NaOH solu-

tion. The endpoint is reached when solution color changes

from yellow to blue.

5.4

Blank

5.4.1

Bulb

pipet exactly 25 ml hydrochlorination reagent into

a 250 ml Erlenmeyer flask.

5.4.2

Add

five drops bromothymol blue 0.1% solution with

an eye dropper.

5.4.3

Titrate

blank to endpoint with 0.1 N NaOH solution.

The endpoint is reached when solution color changes from

yellow to blue.

5.5

Disposal of Solutions

5.5.1 0.1 N NaOH in Methanol, Unused

This

solution is

dilute and readily soluble in water, hence it can be safely

poured down the sink. Flush with excess water.

5.5.2

All Other Solutions

NOT POUR DOWN THE

SINK. Place the solutions in appropriate, labeled, metal con-

tainers to be buried or burned in accordance with local, state,

and federal regulations.

5.6

Cleaning Glassware

Use

soap and water to clean any

glassware. Rinse well with excess water.

5.7

Safety and Handling, First Aid

See

6.3 and 6.4.

6 Notes

6.1

Calculations:

(B−A) x 0.4

sample x specific gravity (1)

= Total Acid Acceptance as % of NaOH

where:

= ml of 0.1 N NaOH used to titrate sample

B = ml of 0.1 N NaOH used to titrate blank

(1)

See sale specification for specific gravity of solvent choice.

6.2

Interpreting Test Results*

Chlorinated

Solvent

Methylene

Chloride

1,1,1-

Trichloroethane

Perchloroethylene

Within Normal

Range

>0.08%

>0.04%

Solvent is Borderline

Check Daily

0.04%-0.08%

≤0.04%

A) Discard

B) Remove, distill blend

with virgin solvent at 4

parts virgin solvent, 1

part distilled.

<0.04%

*Note: These

guidelines have been established using inhibited chlorinated solvents from the

Dow Chemical Company. The solvent manufacturer should be consulted for particular inter-

pretation.

6.3

Safety and Handling

6.3.1 Sampling Procedure

Wear

safety goggles and neo-

prene or neoprene-coated gloves. Have adequate ventilation.

Avoid sparks or flames.

6.3.2

Laboratory Procedure

There

are no unusual haz-

ards inherent in this method, but good ventilation and normal

laboratory safety precautions should be employed. When pre-

paring reagents, mixing should be employed in a hood and

chemical goggles should be worn. Keep away from any

sparks or flames.
