6.6.1.4
Place
the 0Ω (short) calibration standard on the test
head as prompted on the unit’s monitor and press Return on
the unit’s keyboard or ‘‘x1’’ on the unit.
6.6.1.5
Place
the 50Ω calibration standard on the test head
as prompted on the unit’s monitor and press Return on the
unit’s keyboard or ‘‘x1’’ on the unit.
6.6.1.6 Place
the HP 16453A test fixture or equivalent on
the test head as specified in accordance with the manufactur-
er’s instructions as prompted on the unit’s monitor.
6.6.1.7 Open
the fixture gap and lock it open as prompted
on the monitor and press Return on the unit’s keyboard or
‘‘x1’’ on the unit.
6.6.1.8
Short
the fixture gap as prompted on the monitor
and press Return on the unit’s keyboard or ‘‘x1’’ on the unit.
6.6.1.9
Place
the pure PTFE specimen in the fixture in close
contact with electrodes and with the PTFE specimen not
touching the back wall of the fixture, then press Return on the
unit’s keyboard or ‘‘x1’’ on the unit. Pull out the PTFE and
recheck. Permittivity should be within ± 0.01 or ± 0.02 units.
If not, recalibrate starting at ‘‘Fixture.’’ If it is still off, redo the
calibration from beginning.
6.6.1.10
Test
the sample in accordance with Section 5.
6.6.2
The
following calibration/test program is the latest ver-
sion of what was developed for the P H4291A. Using a text
editor (no embedded coding), enter this program on a DOS-
formatted disk and name it ‘‘AUTOST.’’ Place the disk in the
unit and turn it on (If you have any improvements PLEASE for-
ward them to the IPC): The program disk will calibrate and
configure the instrument’s screen. Two windows will appear.
The top window should be permittivity (E’r) and the bottom
window should be loss tangent (δ). Both windows should be
set to the frequency range entered in 6.3.1.2. If they are not,
return to 6.3.1 and repeat the process.
100 !**** PLEASE SET PTFE THICKNESS ON LINE 1610 AND
2600 ****
110 !**** PLEASE SET PTFE PERMITTIVITY ON LINE 2580
****
120 !**** PLEASE SET PTFE LOSS TANGENT ON LINE 2590
****
130 !****
200 !**** SAVE THIS PROGRAM ON A DOS FORMATTED
210 !**** DISK USING A TEXT EDITOR (LINES 100-5000
220 !**** NAME THE PROGRAM ‘‘AUTOST’’ WITH NO
EXTENSION
230 !**** PLACE DISK IN UNITS DRIVE AND TURN UNIT ON
240 !**** PROGRAM WILL AUTOMATICALLY RUN. TO
RESET
250 !**** UNIT FOR NEW FREQUENCY RANGE PRESS
‘‘STOP’’
260 !**** ON UNITS FACE THEN ‘‘START’’ ON UNITS FACE.
270 !**** IF YOU WANT TO RE-CALIBRATE ANSWER YES [1]
280 !**** WHEN PROMPTED
290 !****
1000 !**** INITIALIZE UNIT FOR TEST ***
1010 ASSIGN @Hp4291 TO 800
1020 Scode=8
1030 CLEAR @Hp4291
1040 ABORT Scode
1050 OUTPUT @Hp4291;‘‘DISP:ALL BST’’
1070 !
1100 !**** CALIBRATION STATE CHECKING ****
1110 OUTPUT @Hp4291;‘‘SENS:CORR1?’’
1120 ENTER @Hp4291;Stat
230 IF Stat THEN
1130 INPUT ‘‘RE-CALIBRATE NOW? [1] Yes; [0] No
[RETURN OR x1]’’,Ans$
1140 IF Ans$<>‘‘1’’ THEN GOTO Test_loop
1150 END IF
1160 !
1200 !**** SETTING UP START/STOP FREQUENCY ****
1210 INPUT ‘‘Enter Start Frequency in MHz, [RETURN OR
x1]’’,A
1220 B=A*1000000
1230 OUTPUT @Hp4291;‘‘SENS:FREQ:STAR ’’;B
1240 INPUT ‘‘Enter Finish Frequency in MHz, [RETURN OR
x1]’’,A
1250 B=A*1000000
1260 OUTPUT @Hp4291;‘‘SENS:FREQ:STOP ’’;B
1270 !
1300 !**** SETTING ENABLE REGISTER FOR SRQ ****
1310 OUTPUT @Hp4291;‘‘STAT:INST:ENAB 256’’
1320 OUTPUT @Hp4291;‘‘*SRE 4’’
1330 !
1400 !**** SETTING TRIGGER SOURCE INTERNAL, CON-
TINUOUS OFF ****
1410 OUTPUT @Hp4291;‘‘TRIG:SOUR INT’’
1420 OUTPUT @Hp4291;‘‘INIT:CONT OFF’’
1430 !
1500 !**** SETTING CAL MODE TO FIXED/USER ****
1510 OUTPUT @Hp4291;‘‘SENS:CORR1:COLL:FPO USER’’
1520 OUTPUT @Hp4291;‘‘SENS:CORR2:COLL:FPO USER’’
IPC-TM-650
Number
2.5.5.9
Subject
Permittivity
and Loss Tangent, Parallel Plate,
1 MHz to 1.5 GHz
Date
11/98
Revision
P
age3of5
电子技术应用　　　　　　　ｗｗｗ．ＣｈｉｎａＡＥＴ．ｃｏｍ
1530
!
1600 !**** SET PTFE STANDARD THICKNESS IN METERS
ON LINE 1610****
1610 OUTPUT @Hp4291;‘‘CALC:MATH1:DIM1 0.00075’’
1620 !
1700 !**** MEASUREMENT TYPE er’ AND tan delta ****
1710 OUTPUT @Hp4291;‘‘DUAM DRLT’’
1720 !
1800 !**** FORMAT LINES LIN Y-AXIS ****
1810 OUTPUT @Hp4291;‘‘DISP:TRAC:Y:SPAC LIN’’
1820 !
1900 !**** SWEEP SETTINGS ****
1910 OUTPUT @Hp4291;‘‘SENS:SWE:SPAC LOG’’
1920 OUTPUT @Hp4291;‘‘SENS:SWE:TIME:AUTO ON’’
1930 OUTPUT @Hp4291;‘‘SENS:SWE:POIN 256’’
1940 OUTPUT @Hp4291;‘‘SENS:SWE:DWEL1:AUTO ON’’
1950 !
2000 !**** CHANNEL 1 SETUP ****
2010 OUTPUT @Hp4291;‘‘INST CH1’’
2020 OUTPUT @Hp4291;‘‘CALC:FORM REAL’’
2030 OUTPUT @Hp4291;‘‘DISP:TRAC1:STAT ON’’
2040 OUTPUT @Hp4291;‘‘DISP:TRAC1:Y:BOTT 1’’
2050 OUTPUT @Hp4291;‘‘DISP:TRAC1:Y:TOP 12’’
2060 OUTPUT @Hp4291;‘‘CALC:EVAL:ON’’‘‘TR1’’’’’’
2070 OUTPUT @Hp4291;‘‘CALC:EVAL:Y:XPOS 1MHZ’’
2080 OUTPUT @Hp4291;‘‘CALC:EVAL:MST ON’’
2090 !
2200 !**** CHANNEL 2 SETUP ****
2210 OUTPUT @Hp4291;‘‘INST CH2’’
2220 OUTPUT @Hp4291;‘‘CALC:FORM LTAN’’
2230 OUTPUT @Hp4291;‘‘DISP:TRAC1:STAT ON’’
2240 OUTPUT @Hp4291;‘‘DISP:TRAC1:Y:BOTT -0.5’’
2250 OUTPUT @Hp4291;‘‘DISP:TRAC1:Y:TOP 1.5’’
2260 OUTPUT @Hp4291;‘‘CALC:EVAL:ON’’‘‘TR1’’’’’’
2270 OUTPUT @Hp4291;‘‘CALC:EVAL:Y:XPOS 1MHZ’’
2280 OUTPUT @Hp4291;‘‘CALC:EVAL:MST ON’’
2290 OUTPUT @Hp4291;‘‘INST CH1’’
2300 !
2400 !**** SETUP AVERAGING ****
2410 OUTPUT @Hp4291;‘‘SENS:AVER1 ON’’
2420 OUTPUT @Hp4291;‘‘SENS:AVER1:COUN 10;STAT
ON’’
2430 !
2500 !**** SELECT 16453A FIXTURE AND COMPENSATE ****
2510 !**** PLEASE SET PTFE STANDARD PERMITTIVITY ON
LINE 2580 ****
2520 !**** PLEASE SET PTFE STANDARD LOSS TANGENT
ON LINE 2590 ****
2530 !**** PLEASE SET PTFE STANDARD THICKNESS IN
METERS ON LINE 2600 ****
2540 OUTPUT @Hp4291;‘‘DISP:FORM ULOW’’
2550 OUTPUT @Hp4291;‘‘DISP:ALL BST’’
2560 OUTPUT @Hp4291;‘‘SYST:FIXT HP16453’’
2570 OUTPUT @Hp4291;‘‘SENS:CORR2:CKIT2 TEFL’’
2580 OUTPUT @Hp4291;‘‘SENS:CORR2:CKIT2:STAN6:PRE
2.1’’
2590 OUTPUT @Hp4291;‘‘SENS:CORR2:CKIT2:STAN6:PLF
0.0001’’
2600 OUTPUT @Hp4291;‘‘SENS:CORR2:CKIT2:STAN6:
THIC 0.00075’’
2610 OUTPUT @Hp4291;‘‘SENS:CORR2:CKIT2:SAVE’’
2620 !
2700 !**** OPEN STANDARD MEASUREMENT ****
2710 ON INTR Scode GOTO Open_end
2720 OUTPUT @Hp4291;‘‘*CLS;*OPC?’’
2730 ENTER @Hp4291;Opc
2740 INPUT ‘‘CONNECT OPEN (OS) STANDARD, THEN
PRESS [RETURN OR x1]’’,A$
2750 ENABLE INTR Scode;2
2760 OUTPUT @Hp4291;‘‘SENS:CORR1:COLL STAN1’’
2770 Wait_open:GOTO Wait_open
2780 Open_end:!
2790 !
2900 !**** SHORT STANDARD MEASUREMENT ****
2910 ON INTR Scode GOTO Short_end
2920 OUTPUT @Hp4291;‘‘*CLS;*OPC?’’
2930 ENTER @Hp4291;Opc
2940 INPUT ‘‘CONNECT SHORT (0 OHM) STANDARD,
THEN PRESS [RETURN OR x1]’’,A$
2950 ENABLE INTR Scode;2
2960 OUTPUT @Hp4291;‘‘SENS:CORR1:COLL STAN2’’
2970 Wait_short:GOTO Wait_short
2980 Short_end:!
2990 !
3100 !**** 50 OHM LOAD STANDARD MEASUREMENT ****
3110 ON INTR Scode GOTO Load_end
3120 OUTPUT @Hp4291;‘‘*CLS;*OPC?’’
3130 ENTER @Hp4291;Opc
3140 INPUT ‘‘CONNECT 50 OHM STANDARD, THEN
PRESS [RETURN OR x1]’’,A$
3150 ENABLE INTR Scode;2
3160 OUTPUT @Hp4291;‘‘SENS:CORR1:COLL STAN3’’
3170 Wait_load:GOTO Wait_load
3180 Load_end:!
3190 !
3300 !**** SAVE UNIT CALIBRATION ****
3310 OUTPUT @Hp4291;‘‘SENS:CORR1:COLL:SAVE’’
3320 !
IPC-TM-650
Number
2.5.5.9
Subject
Permittivity
and Loss Tangent, Parallel Plate,
1 MHz to 1.5 GHz
Date
11/98
Revision
P
age4of5
电子技术应用　　　　　　　ｗｗｗ．ＣｈｉｎａＡＥＴ．ｃｏｍ
3330
!**** END CALIBRATION OF UNIT ****
3340 !
3400 !**** OPEN 16453A FIXTURE MEASUREMENT ****
3410 ON INTR Scode GOTO Open_end1
3420 OUTPUT @Hp4291;‘‘*CLS;*OPC?’’
3430 ENTER @Hp4291;Opc
3440 INPUT ‘‘CONNECT FIXTURE AND LOCK GAP OPEN,
THEN PRESS [RETURN OR x1]’’,A$
3460 ENABLE INTR Scode;2
3470 OUTPUT @Hp4291;‘‘SENS:CORR2:COLL STAN4’’
3480 Wait_open1:GOTO Wait_open1
3490 Open_end1:!
3500 !
3600 !**** 16453A FIXTURE SHORT MEASUREMENT ****
3610 ON INTR Scode GOTO Short_end1
3620 OUTPUT @Hp4291;‘‘*CLS;*OPC?’’
3630 ENTER @Hp4291;Opc
3640 INPUT ‘‘CLOSE AND SHORT FIXTURE GAP, THEN
PRESS [RETURN OR x1]’’,A$
3650 ENABLE INTR Scode;2
3660 OUTPUT @Hp4291;‘‘SENS:CORR2:COLL STAN5’’
3670 Wait_short1:GOTO Wait_short1
3680 Short_end1:!
3690 !
3800 !**** TEFLON LOAD IN 16453A MEASUREMENT ****
3810 ON INTR Scode GOTO Load_end1
3820 OUTPUT @Hp4291;‘‘*CLS;*OPC?’’
3830 ENTER @Hp4291;Opc
3840 INPUT ‘‘PLACE TEFLON STANDARD INTO FIXTURE,
THEN PRESS [RETURN OR x1]’’,A$
3850 ENABLE INTR Scode;2
3860 OUTPUT @Hp4291;‘‘SENS:CORR2:COLL STAN6’’
3870 Wait_load1:GOTO Wait_load1
3880 Load_end1:!
3890 !
4000 !**** SAVE FIXTURE COMPENSATION SETTINGS ****
4010 OUTPUT @Hp4291;‘‘SENS:CORR2:COLL:SAVE’’
4020 !
4030 !**** REPLACE PROGRAM DISK WITH DATA DISK ****
4040 INPUT ‘‘Replace Program with Data Disk, [RETURN OR
x1]’’,A$
4050!
4100 !**** PERMITTIVITY TEST LOOP ****
4110 Test_loop:!
4120 OUTPUT @Hp4291;‘‘INIT:CONT OFF’’
4130 Sweep1_Begin:!
4140 INPUT ‘‘Place Sample In Fixture, Enter Thickness In
mm, [RETURN OR x1]’’,A
4150 B=A/1000
4160 OUTPUT @Hp4291;‘‘CALC:MATH1:DIM1 ’’;B
4170 ON INTR Scode GOTO Sweep1_end
4180 OUTPUT @Hp4291;‘‘STAT:INST:ENAB 1’’
4190 OUTPUT @Hp4291;‘‘*SRE 4’’
4300 OUTPUT @Hp4291;‘‘*CLS;*OPC?’’
4310 ENTER @Hp4291;Opc
4320 OUTPUT @Hp4291;‘‘ABOR’’
4330 ENABLE INTR Scode;2
4340 OUTPUT @Hp4291;‘‘INIT’’
4350 Waiting:GOTO Waiting
4360 Sweep1_end:!
4370 !
4400 !**** SAVE DATA ROUTINE ****
4410 INPUT ‘‘SAVE DATA? [1] Yes; [0] No [RETURN OR
x1]’’,Ans$
4420 IF Ans$<>‘‘1’’ THEN GOTO Sweep1_Begin
4430 INPUT ‘‘Input Job Number [RETURN OR x1]:’’,Job$
4440 OUTPUT @Hp4291;‘‘MMEM:STOR:DINT:TRAC SEL,
‘‘‘‘‘‘;Job$;’’’’‘‘,’’‘‘DISK’’‘‘;’’
4450 GOTO Sweep1_Begin
4460 !**** END MEASUREMENT LOOP *****
4470 !
5000 END
