5|Commissioning
5.3.7 Indicator lamp: Perform light test
Open the setting dialog [Messages] to test the indicator lamp. With regard to this,
please read Chapter [Functional description].
Lamp test
ü Testing the lamps and the horn:
a) Click on the
button.
ð All lights of the signal lamp must be lit. The horn must sound.
ü If not all lights are illuminated, or if the horn does not sound:
a) Have the indicator lamp checked by a qualified electrician.
b) Have a qualified electrician replace damaged components.
ð The process has now been completed.
5.3.8 Checking the safety equipment
ü If hoods, protection covers and doors are fitted with safety switches:
a) Open caps, protection covers and doors.
b) Check that the corresponding error messages are displayed on the operator
terminal and signal lamp.
c) Close caps, protection covers and doors. Acknowledge messages.
d) Finally, check all system parts for proper operation.
Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 99/695
5|Commissioning
5.3.9 Referencing modules
Referencing must always be carried out in the following cases:
– After a breakdown of the CAN motors power supply
– after pressing the emergency STOP
– after a power failure
– after switching off the main switch
– after an adjustment
NOTE
Are any changes possible?
The [Module properties] user rights are required to access this dialog. Settings can
only be displayed if no name and password are logged in. In this case, press the [ESC]
key on your keyboard, or click on the [Cancel] button when a password is required.
For referencing, you must open the input dialog of the relevant modules. When ref-
erencing, the relevant reference limit switches are approached and the appropriate
module is referenced.
ü Should this not be possible, or referencing fail:
a) Identify the cause of the error in the [Messages] input dialog.
b) Correct the error, then acknowledge the message.
c) Carry out referencing again.
ü How to reference a module:
a) Set the machine to the [Maintenance mode] operating mode.
b) In the start dialog, open the settings dialogs of the module to be referenced:
Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 100/695
5|Commissioning
Preheating Soldering module ExitInfeed Infeed unit
Solder pot
user: none
Flux unit
Maintenance mode
Fig.17: Start dialog of the control software:
5.3.9.1 Referencing the fluxer module
ü To reference the fluxer module, proceed as follows:
a) In the start dialog in the [Fluxing] frame, click on the symbol of the flux module.
ð The [Flux unit] inpput dialog is opened.
b) In the [Special positions] frame, click on the
button to start the referencing
process.
ð The process has now been completed.
NOTE
The travel movement requires a certain amount of time.
a) In the meantime, do not perform any inputs.
b) During referencing, the
symbol is displayed next to a moving axis in the setting
dialog.
ü Checking the X and Y positions:
a) Compare the actual values with the entered set values.
b) Readjust any deviation Then repeat referencing.
