5|Commissioning
NOTE
In case of power failure
After power failure, all applicable modules must be referenced again!
5.6.4 Manual shutdown for a longer period of time
Should the machine be taken out of service for an extended period of time, per-
form the following steps:
ü The machine must be stopped via the start dialog of the control software.
a) Is there still any board inside the machine? Let it be processed and wait until
there are no more boards inside the machine.
b) On the top toolbar of the start dialog, click on the
button. The following dia-
log box is displayed:
Select soldering program
Finish job before maintenance mode
Stop current job and empty the machine
Stop current job
c) Select [Stop current job] and then click on .
ð The
(red) button appears in the top toolbar of the start dialog. The ma-
chine is in the [Maintenance mode] operating mode.
d) Click on
(red) in the top toolbar of the start dialog.
ð The button changes into
(green). The machine is in the [Movement off]
operating mode. Some modules continue to run in accordance with their
switch-off delay.
Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 115/695
5|Commissioning
e) Wait until the switch-off delays have expired.
a) Turn the main switch to the OFF position and secure it with a safety lock!
Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 116/695
5|Commissioning
5.7 Backing up all data on the machine
NOTE
Regularly back up data!
– After commissioning, first back up data!
– Back up data on a quarterly basis!
– If the control PC is faulty, your data may be unusable. Back up data on an ex-
ternal disk once a year! Data is stored in the [Data storage] folder. With respect
to this, please read chapter [File path]!
– Document each data backup and store it in a safe place!
ü To perform the data storage of all messages, process data and soldering pro-
grams:
a) Always use an external archive device for data storage.
b) In addition, check the list of users for accuracy and completeness. Check the
permissions of all users and reassign them if necessary.
ð The process has now been completed.
