9|Spare and wear parts
9.8.18 Process observation (single track) Eccentric nozzle, double travel
1 24 573
8
6
9
10
Fig.342: EM113-66-50-00
Pos Description Item number A B
1 Glass mirror 58 x 32 x 3 mm 186504 x
2 Glass plate 38 x 45 x 3 mm 186503 x
3 Illuminant, halogen, cold light 24V / 35W 186541 x
4 Halogen spot, camera BG 186485 x
5 1/3“ color-CCD camera CS mount 109126 x
6 25 mm C-Mount lens F1,4 109129 x
7 Polarizing filter, linear 109131 x
8 Screw 1/4“X5/16“, (stainless steel) 160870 x
9 Bearing 6LA6082RS x
10 Swivel head M6, plastic 187338 x
Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 627/695
9|Spare and wear parts
9.8.19 Process observation (single track) Eccentric nozzle, y-variable
1
2
4
3
Fig.343: EM113-23-00d
Pos Description Item number A B
1 Illuminant, halogen, cold light 24V / 35W 186541 x
2 1/3“ color-CCD camera CS mount 109126 x
3 25 mm C-Mount lens F1,4 109129 x
4 Polarizing filter, linear 109131 x
Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 628/695
9|Spare and wear parts
9.8.20 Fiducial recognition and deflection measurement
1 2634 5
Fig.344: EM113-85-00a
Pos Description Item number A B
1 Cover glass, transparent 198509 x
2 Protective grid (Papst) 182901 x
3 Fan (Papst), 24V DC 202474 x
4 Hose, inside Ø 51 mm, temperature resistant up to 310° C 118351 x
5 Filter 236235 x
6 Laser distance sensor 200106 x
Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 629/695
