6.10.5 Changing an assignment

You can change an assignment by attributing a new code to the soldering program.

The assignment code – Changing the soldering programme

ü Changing an assignment:

a) in the [Assignment: code - soldering program] frame, highlight the data set to

be changed.

ð The data set is now displayed in the input line.

b) Change the code in the [Code] input field.

c) Click on the

button in the [Assignment: code - soldering program] frame

ð A new code was assigned to the soldering programme.

NOTE

When the [Code mode] checkbox is enabled

In this case, the machine works in [Code mode]. This necessarily requires an enabled

code table. The machine then operates as shown in the code table.

6.10.6 Deleting, rename and copy a code table

Deleting a code table

ü Deleting a code table together with the data sets it contains:

a) in the [Code table] frame, highlight a code table and then click on the

but-

ton.

ð A query dialogue is displayed.

b) Follow the instructions on the screen.

ð The code table has been deleted.

Renaming a code table

ü Renaming a code table:

a) in the [Code table] frame, highlight a code table and then click on the

but-

ton.

ð The [Rename file] dialogue is displayed.

b) Enter a new name for the code table in the input field.

c) Should the process be cancelled, click on the

button.

d) Click on the

button.

ð The code table has been renamed

NOTE

Can a code table not be deleted or renamed?

If a code table is enabled, you cannot delete or rename it. You first have to enable an

other code table. The last code table in the [Code table] frame cannot be deleted or

renamed.

Copying a code table

ü Copying a code table together with the data sets it contains:

Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 213/695

6|Function description

a) In the [Code table] frame, highlight a code table and then click on the but-

ton.

ð The [Copy file] dialogue is displayed.

b) Enter a new name for the copy in the input field.

c) Should the process be cancelled, click on the

button.

d) Click on the

button.

ð The code table has been copied together with the data sets contained therein.

6.10.7 Enabling a code table

Once code tables have been created, you can select and enable them.

ü Enabling a code table

a) Mark a code table in the [Code table] frame, then click on the

button.

ð The code table is enabled and shown in the [Activated code table:] display

field.

6.10.8 Code read error

If a code which has not been assigned is read at the machine infeed, a message is

displayed. After acknowledging the message, the [Code Failure] dialogue is dis-

played. You have three options:

– [remove PCB]. Remove the PCB from the infeed.

– [Select soldering program manually]. Create the appropriate assignment manu-

ally.

– [Use as code in code table]. Click the

button. Follow the instructions on the

screen to add the code to the appropriate code table.
