9|Spare and wear parts
9.1 Read this first!
9.1.1 Nameplate and machine number
Maschinen-Nr./machine no.: S022A-15G0016
Max. Vorsicherung/max. fuse rating: 3 x 35 A
träge/slow
Netzanschluss/power supply: 3 /phase/N/PE
Anschlussdrähte/wire: 5
Schaltschrank IP-Klasse/IP rating control cabinet 21
Absaugmenge/exhaust: 200 m
3
/h
Gewicht/weight 900 kg
Druckluftanschluss/compressed air: opt. min. 6 bar, max. 8 bar
Stickstoffanschluss/nitrogen supply: opt. min. 6 bar, max. 10 bar
ERSA GmbH 97877 WERTHEIM, G
ERMANY
Typ/type: Smartflow 2020
Lötanlage/soldering system
Baujahr/year of manufacture: 07.2015
P
N
: 22 kW U
N
: 230/400 VAC
I
N
: 33,5 kW f
N
: 50 / 60 Hz
Fig.175: Example for the rating
plate of a machine. The details are
not identical with the rating plate
on the machine!
NOTE
Important note
Always state the machine number when ordering spare parts. You will find this num-
ber on the rating plate (see illustration). The rating plate contains further important
information about the machine such as machine type, manufacturing date, electrical
load ratings, notes on compressed air and, if applicable, nitrogen connection, con-
formity symbol and the address of the machine manufacturer.
Spare or wearing part?
The spare and wear parts are listed in table form. The last two columns mark the
parts either as
– wearing part (A) or as
– spare part (B).
Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 446/695
