2|Technical data
2.1 Technical data of the entire system
2.1.1 General system data*
Designation
Length (mm) 2450
Width (mm) 1700
Height (mm) 1540
Height, open hood (mm) 2060
Weight (kg) 1100
Painting RAL 7035 / RAL 7016
*The technical drawings of your machine are in the Appendix of this manual.
2.1.2 Pneumatics
Designation
Minimum input pressure (bar) 6
Maximum air consumption (m
3
/h) 5
Required connection (hose) NW8
2.1.3 Protective gas technology (nitrogen)
Designation
Minimum input pressure (bar) 6
Protective gas supply to the soldering
unit point and path approx. (l/min)
25
Protective gas supply to the DIP solder-
ing unit approx. (l/min)
420
Recommended degree of purity (equi-
valent to a degree of purity of 99.999%
or max. 10ppm of other gases)
5.0
Nitrogen consumption per soldering unit
point and path approx. (m
3
/h)
2
Nitrogen consumption per DIP soldering
unit approx. (m
3
/h)
25
Required connection (hose) NW 8
2.1.4 Extraction capacity
Description
Exhaust support (piece / Ø mm)* 2 / 150
Total suction capacity approx. (m
3
/h)* 450
* Depending on the particular configuration level. Actual values can be found in the
annex to this instruction manual.
