6|Function description
6.13.1 Machine operating data
In this dialog, you can view or change the machine operating data. Additionally you
will find information about the quantity of processed boards.
ü Displaying the [Operating data] editing dialog:
a) Enable the [Operating data] radio button.
ð The machine operating data is displayed.
User ersa Maintenance mode
Soldering report and operating data
Operating data
Operating data
Operating data
Soldering report
Running times
Time in maintenance mode
Time in production mode
Waiting time while production mode
Waiting time congestion successor
Total time
Number of boards
Currently in machine
Total boards
Produced boards
Defective boards
Waiting time while production mode
Waiting time congestion successor
(N-1)
(N+1)
(N-1)
(N+1)
Selection
Delay time to counter start
Fig.55: The [Soldering report and operating data] input dialog
NOTE
Are any changes possible?
The [Administrator] user rights are required access this dialog. Settings can only be
displayed if no name and password are logged in. In this case, press the [ESC] key on
your keyboard, or click on the button [Cancel] when a password is required.
Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 222/695
6|Function description
Reading working times in the [Running times] frame
In this frame, you can read the following:
– [Time in maintenance mode] shows how long the machine has been in the
[Maintenance mode ] operating mode since commissioning.
– [Time in production mode] shows how long the machine has been in the oper-
ating mode [Automatic mode] and how long it has been soldering.
– [Waiting time while production mode] (N-1) shows how long the machine has
been in the [Automatic mode] operation mode and has not been soldering be-
cause no more PCBs were delivered by the upstream system.
– [Waiting time congestion successor] (N+1) shows how long the machine has
been in the operating mode [Automatic mode] and has not been soldering be-
cause PCBs could not be removed by the downstream system.
– [Total time] shows the machine operating hours since commissioning.
Reading piece numbers in the [Numbers of Boards] frame
In this frame, you can read the following:
– [Currently in machine] shows how much solder material is currently inside the
machine.
– [Total boards] shows how much solder material has been processed error-free
since commissioning.
– [Produced boards] shows how much solder material has been processed error-
free since commissioning.
– [Defective boards] shows how much solder material has been processed error-
free since commissioning.
Changing times and counter readings
ü To change times and counter readings:
a) Click on the
button in the bottom toolbar.
ð Editable input fields appear now highlighted in white.
b) Click on the desired input field and enter the value.
ü Accept settings, close dialogs
a) Click on
to accept a setting.
b) Click on
to close a dialog.
NOTE
Why may discrepancies result in the counter readings?
If boards are removed from the machine during the production process, counting dif-
ferences between the boards fed into the machine and those actually produced may
result. Counter readings can therefore be changed. If counter readings were changed,
counting is continued from the counter reading which you entered.
Delayed counters start in the [Delay time to counter start] frame
For the [Waiting time while production mode] (N-1) and [Waiting time congestion
successor] (N+1), you can enter a delay time into the [Running times] frame. When
the event occurs, the counter starts only when time is up.
In this frame, you can read the following:
– [Waiting time while production mode] (N-1) shows the delay time up to
counter start.
Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 223/695
6|Function description
– [Waiting time congestion successor] (N+1) shows the delay time up to counter
start.
An example:
ü The [Waiting time while production mode] (N-1) delay time shall be 3 seconds.
a) Enter value 3 in the input field.
ð If the upstream system delivers no more boards, the above time begins to run.
If after 3 seconds still no PCBs are available at the infeed, the [Waiting time
while production mode] time is started in the [Running times] frame.
