6|Function description 6.11 Selecting and starting a soldering program Use this function to select and start a previously created soldering programme. After starting, the machine switches to the [Automatic mode] operat…

6|Function description

a) In the [Code table] frame, highlight a code table and then click on the but-

ton.

ð The [Copy file] dialogue is displayed.

b) Enter a new name for the copy in the input field.

c) Should the process be cancelled, click on the

button.

d) Click on the

button.

ð The code table has been copied together with the data sets contained therein.

6.10.7 Enabling a code table

Once code tables have been created, you can select and enable them.

ü Enabling a code table

a) Mark a code table in the [Code table] frame, then click on the

button.

ð The code table is enabled and shown in the [Activated code table:] display

field.

6.10.8 Code read error

If a code which has not been assigned is read at the machine infeed, a message is

displayed. After acknowledging the message, the [Code Failure] dialogue is dis-

played. You have three options:

– [remove PCB]. Remove the PCB from the infeed.

– [Select soldering program manually]. Create the appropriate assignment manu-

ally.

– [Use as code in code table]. Click the

button. Follow the instructions on the

screen to add the code to the appropriate code table.

Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 214/695

6|Function description

6.11 Selecting and starting a soldering program

Use this function to select and start a previously created soldering programme.

After starting, the machine switches to the [Automatic mode] operating mode and

you can proceed to solder using the settings of the soldering program.

Searching for a soldering programme

ü Searching for a soldering programme:

a) click on the

button in the top toolbar of the start dialogue.

ð When the [Password:] input field appears:

b) enter user name and correct password.

ð If the [Moduleinfo] edit dialogue appears, there is either a malfunction or

an operating condition preventing soldering programmes from starting.

You cannot select any soldering programme.

c) Check for existing malfunctions in the [Moduleinfo] edit dialogue.

d) Eliminate malfunctions. Then try again to start a soldering programme.

ð The dialogue [Select soldering program] is displayed.

NOTE

Are any changes possible?

The [Select soldering program] user rights are required to access this dialog. Settings

can only be displayed if no name and password are logged in. In this case, press the

[ESC] key on your keyboard, or click on the button [Cancel] when a password is re-

quired.

After entering [User name] and [Password:] correctly, the [Select soldering pro-

gram] dialog is displayed:

Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 215/695

6|Function description

Libraries Programs

Libraries selection Program selection

Board simulation

Select soldering program

Code mode

Filter soldering programmes

ü Using the filter function:

a) click on the [Program selection] input field and enter any desired character

string.

ð If you enter, for example, the character string [ec], all file names in which this

string is included, will be displayed in our example [TechDok].

ü Enabling a soldering programme:

a) highlight a library in the [Libraries] frame.

b) Highlight a soldering programme in the [Programs] frame.

c) Should the process be cancelled, click on the

button.

ð The dialogue closes.

d) If the soldering programme is to be selected and enabled, click on the

but-

ton.

ð The soldering programme is enabled and the dialogue closed. The machine

switches to the [Automatic mode] operating mode. The

button is displayed

in the top toolbar. The operating mode, the library and the selected soldering

programme are displayed in the status bar.

Ersa GmbH Operating Instructions_VF335_en|Rev. 14|30/11/2017 216/695
