10-4 Fast & Flexible Chip Shooter DECAN F2 Service Manual  Use the Y Motor Coil assembly at JIG . Assemble the Y motor magnet with the PIN being in tig ht contact with the top surface of the Y frame. Ref The part nu…

10-3

Y-Axis Frame

5) Remove the Cable that is connected to the Linear Motor.

6) Unscrew the fixing bolts (7-M5*15)securing the Linear Motor using a wrench and

remove it.

7) Assemble in the X Fame a new Linear Motor.

Ref The part number of the new Linear Motor is EP08-000198.

10-4

Fast & Flexible Chip Shooter DECAN F2 Service Manual

Use the Y Motor Coil assembly at JIG.

Assemble the Y motor magnet with the PIN being in tight contact with the top

surface of the Y frame.

Ref The part number of the jig used for the Y motor coil is TO04-

000612A.

Caution When assembling the linear scale, exercise care so that

insulation material is not left out.

8) The assembling is performed in the reverse order of disassembling. Turn on the main

switch on the front side of the machine and boot the PC once the assembling is

completed.

9) Perform the following calibrations.

 Axis Home Calibration

 Common X-Y (1'st)

10-5

Y-Axis Frame

 X-Xy Compensation

 Common X-Y (2'nd)

 Thermal Mapping

 Gantry Mapping

 ANC, Position Teaching

 S/W ABS ST700 Signal Adjustment Program - Homing Setting

 Time: 1 hour

Ref In the case of the standard conveyor option, remove the machine from

the in-line system.

When removing the Y1 axis linear motor, remove/ assemble the X-

axis motor.

Remove/assemble the X-axis motor referring to the X-axis Motor

Replacement Procedure (Page 4-1).
