15-1 Electric Device Chapter15. Electric Device 15.1. Power Supply 15.1.1. Required Tools Crosshead (Phillips) screwdriv er and flathead screwdriver T W rench or Hex W rench 15.1.2. Power Supply R eplacement Procedur…
15-1
Electric Device
Chapter15. Electric Device
15.1. Power Supply
15.1.1. Required Tools
Crosshead (Phillips) screwdriver and flathead screwdriver
T Wrench or Hex Wrench
15.1.2. Power Supply Replacement Procedure
1) Close the PC as usual and turn off the main switch at the front of the machine.
2) Turn off the main power supply to the machine.
Warning Before servicing the machine, turn off the power switch
located at the front bottom as well as the main circuit
breaker at the rear bottom of the machine. Otherwise,
serious personal injury may occur. Perform servicing with
the power supply to the machine cut off without fail.
15-2
Fast & Flexible Chip Shooter DECAN F2 Service Manual
3) Remove the front cover.
4) Remove the cable connected to the power supply to be replaced.
