13-50
Fast & Flexible Chip Shooter DECAN F2 Service Manual
13.3. Factory Constant
Module No Name Div Value Unit Description
Machine 19 Machine No
Use Const Machine No.: Set for each machine
20
Machine Type
Use
1
Const Machine Type
0 : Machine with no Upward Vision System
1 : Machine with Upward Vision System
Conveyor 23 Conv Fix Type
Use
0
Const
0 : Front standard of equipment
1 : Rear standard of equipment
24
Board Flow Method
Use
0
Const 0 : Normal
1 : Back Return
27 Conv 1 Type
Use
1 Const
Kind of Conveyor
0: 1 stage Conveyor
1: 3 stage Conveyor
2: 3 stage Motor conveyor
29 Conv 1 Auto width
Use
1
Const Automatic width adjustment function
0 : No automatic width adjustment function
1 : Automatic width adjustment function
31 Board Flow
Use
0
Const PCB transfer direction
0 : Left to right
1 : Right to left
13-51
Software
ANC
25
Sys Delay ANC
Use
50 msec
Select the buzzer type.
26 NZ Get DN Margin
Use
1100 um
The distance through which the head moves down further
to pick a nozzle.
91 UZ Vis Use Chk Value Reser
ved
30 %
When checking for the existence of a nozzle using a
vision system, set the base for the nozzle existence
check to pixel 30%.
Module No Name Div Value Unit Description
13-52
Fast & Flexible Chip Shooter DECAN F2 Service Manual
Vacuum 63 Sys Head Vac Delay Use 5 msec
Time delay from the Z Pulse End until the Vacuum Sol Off
signal is generated.
64 Sys Head Vac Time Use 5
msec Period of time from Vacuum Sol Off until the vacuum is
released.
65 Sys Head Vac Gen
Time
Use
20
msec Period of time from Vacuum Sol On until the vacuum is
created.
66 Sys Head Vac Rel
Time
Use 21
msec Period of time from Vacuum Sol Off until the vacuum
release is stabilized.
67 Sys Head Vac Time2 Reser
ved
170
msec Time of minimum variation when releasing the vacuum.
71 Sys Offset Vac Use 40 um
For the Z measurement using a vacuum, the difference
between the measurement vale and actual value.
Difference in measurement value when using the CN040.
96 Vac Close Detect
ABS
Use
613 mmHg
Absolute value based on when the nozzle is clogged
(used for Z offset, etc.).
97 Vac Close Detect Diff
Use
60 mmHg
Difference in measurement value based on when the
nozzle is clogged (used for Z offset, etc.)
Module No Name Div Value Unit Description
