E1404 AE-Link communication error - I/O Node "0"
[Cause]
Defective NICO board operation
[How to Check]
After checking whether the NCIO board is inserted into the back plane board slot,
check whether the NCIO board cable is properly connected
Replace the NCIO board and check whether the same problem occurs
[Measures]
Insert the NCIO board into the back plane board slot or connect the NCIO board cable
again.
Replace the NCIO board.
E1405 Defective communication with the machine at the previous stage
[Cause]
Incorrect MMI setup
Defective SEMEA cable
Defective Base Control board
Defective I/F protocol with the previous machine
[How to Check]
Defective base control board
Check the SMEMA cable connection
Check the I/F connection with the previous machine (supplied by others) (contact
type, SEMEA type, etc.)
Replace the general I/O board and check whether the same problem occurs
[Measures]
Check the SMEMA I/F setup of the MMI setup.
Check the SMEMA cable connection.
Check the I/F connection with the previous machine (supplied by others).
Replace the general IO board.
E1406 Defective communication with the machine at the next stage
[Cause]
Incorrect MMI setup
Defective SEMEA cable
17-89
Troubleshooting
Defective Base Control board
Defective I/F protocol with the next machine
[How to Check]
Check the I/F setup of the MMI setup
Check the SMEMA cable connection
Check I/F connection with the next machine (supplied by others) (contact type,
SEMEA type, etc.)
Replace the conveyor I/F board
[Measures]
Check the SMEMA I/F setup of the MMI setup.
Check the SMEMA cable connection.
Check the I/F connection with the next machine (or the machine supplied by other
company).
Replace the general IO board.
17-90
Fast & Flexible Chip Shooter DECAN F2 Service Manual
17.3.17. Abnormal control board operation (E15)
E1500 All I/Os on the conveyor operate abnormally
[Cause]
Defective Base Control board
[How to Check]
Check the status of the PCB sensor Conveyor Fiber Sensor Amp in the MMI
Check the cable in the Fiber Sensor Interface Board
Check whether the power supply LED and signal LED of the base control board are
turned on.
[Measures]
Replace the Base Control board.
E1501 The I/F of the head operates abnormally
[Cause]
Defective Head I/F board
[How to Check]
When turning on/off the power supply to the Head I/F board, check whether the valve
homing is performed properly
Check the Head I/F board power supply and signal LED lighting
[Measures]
Replace the head I/F board.
E1502 Defective feeder operation
[Cause]
Cart Control board is defective
[How to Check]
Perform manual feeder operation in the feeder I/O window
Replace the cart control board and check the connector.
Cause Description Remarks
Abnormal control
board operation
All I/Os on the conveyor operate abnormally E1500
The I/F of the head operates abnormally E1501
Defective feeder operation E1502
Vision loading error and Vis frame error occurred E1503
CAN communication error or Vision communication
error
E1504
