13-57 Software 13.4. System Constant Module No Name Div Va l u e Unit Description Machine 21 Opt Door Open Use 34 Const D0-D3 : F ront Door D4-D7 : Rear Door >>0:No Check(NO) 1:Low S peed(LOW) 2:Emergency(EMER) V a…
13-56
Fast & Flexible Chip Shooter DECAN F2 Service Manual
Pick up 84 Use Fast Pick up
Use
1
Const 0: Fast PickUp not used
1: Fast PickUp used
95 Pick Teach xy Method
Use
0
Const Set the function for Pick-Up Position XY Offset correction
during automatic placement.
In order to reflect the corrected offset, the No. 31 Debug
Constant (TAPE_PICK_OFFSET_WEIGHT) must be set
to 1.
0: Not used.
1: Performed when Part Retry Out occurs.
2: Corrected immediately before the set Part Retry Out
Count. When it is NG even after the correction, the
machine stops.
3: Always performed before picking up s part (applicable
to fine parts less than 0402).
Module No Name Div Value Unit Description
13-57
Software
13.4. System Constant
Module No Name Div Value Unit Description
Machine 21 Opt Door Open
Use
34
Const D0-D3 : Front Door D4-D7 : Rear Door
>>0:No Check(NO) 1:Low Speed(LOW)
2:Emergency(EMER)
Value: Front, rear
0 :NO, NO
1:LOW, NO
2:EMER, NO
16:NO, LOW
17:LOW, LOW
18:EMER, LOW
32:NO, EMER
33:LOW, EMER
34:EMER, EMER
13-58
Fast & Flexible Chip Shooter DECAN F2 Service Manual
Tow er
Lamp
4 Opt Sig Type
Use
0
Const Types of tower lamps (used in the MMI)
5 Opt Sig Red
Use
2112
Const Setup for the tower lamp operation
6 Opt Sig Yel
Use
257
Const D0-D1: IDLE
D2-D3: RUN
D4-D5: PAUSE
7 Opt Sig Grn
Use
292
Const D6-D7: FREEZE
D8-D9: ADJUST
D10-D11: EMER
8 Opt Sig Blue
Use
0
Const 0: ACT_OFF
1 : ACT_ON
2 : ACT_BLINK
Module No Name Div Value Unit Description
