Fast & Flexible Chip Shooter DECAN F2 Service Manual
[SM_GANTRY_CA
MERA]
1F_Fid_Camera_
Type= 1
1F fiducial
camera type
1F_Fly_Camera_
Type= 10
1F fly camera
type
1F_Fix_Camera_
Type= 10
1F fix camera
type
1R_Fid_Camera_
Type= 1
1R fiducial
camera type
1R_Fly_Camera_
Type= 10
1R fly camera
type
1R_Fix_Camera_
Type= 10
1R fix camera
type
1F_SWTrigger= 1 Whether to use
the 1F software
trigger
1R_SWTrigger=
1
Whether to use
the 1R software
trigger
1F_NotifyFirstDM
ADone= 1
Improvement of
the image
transmission
sequence of
the fly camera
1R_NotifyFirstDM
ADone= 1
Improvement of
the image
transmission
sequence of
the fly camera
Classification
Item and Default
Value
Description
Remarks
13-17
Software
[SM_HEAD] 1F_Fly_Camera_
HeadNum= 2
Number of
spindles
viewed by one
of the 1F fly
cameras
1R_Fly_Camera_
HeadNum= 2
Number of
spindles
viewed by one
of the 1R fly
cameras
1F_Total_NumHe
ad= 10
Sum of the
number of
spindles
viewed by all
1F cameras
1R_Total_NumHe
ad= 10
Sum of the
number of
spindles
viewed by all
1R cameras
FlyCamerasPerG
antry= 5
Classification
Item and Default
Value
Description
Remarks
13-18
Fast & Flexible Chip Shooter DECAN F2 Service Manual
[DUAL_GANTRY] 1F_Fid_Camera_
Type= 1
1F fiducial
camera type
1F_Fly_Camera_
Type= 10
1F fly camera
type
1F_Fix_Camera_
Type= 10
1F fix camera
type
1R_Fly_Camera_
Type= 10
1R fiducial
camera type
1R_Fix_Camera_
Type= 10
1R fly camera
type
1R_Fid_Camera_
Type= 1
1R fix camera
type
1F_SWTrigger= 1 Whether to use
the 1F software
trigger
1R_SWTrigger=
1
Whether to use
the 1R software
trigger
1F_NotifyFirstDM
ADone= 1
Improvement of
the image
transmission
sequence of
the fly camera
1R_NotifyFirstDM
ADone= 1
Improvement of
the image
transmission
sequence of
the fly camera
2F_Fid_Camera_
Type= 1
2F fiducial
camera type
2F_Fly_Camera_
Type= 10
2F fly camera
type
2F_Fix_Camera_
Type= 10
2F fix camera
type
Classification
Item and Default
Value
Description
Remarks
