13-65 Software V acuum 60 Opt V ac Dump Saver Ti m e O u t Use 300 sec When the head vacuum is not used in the IDLE mode, shut off the vacuum pump af ter a given period of time. 66 Opt Pick V ac Chk Use 19 msec 0: The ro…
13-64
Fast & Flexible Chip Shooter DECAN F2 Service Manual
Docking 63 Opt DC Safety
Use
4
Const It is possible to check the sensors related to docking cart
safety by option:
0: All safety sensors checked
1: Left/right docking detection sensor check cleared
2: Door open state check cleared
4: Docking cart cable connection state check cleared
Mir 32 Opt Use Mir Safety
Use
0
Const Currently set so that it will not change according to the
value.
0 : Not used
1 : Used only for homing
ANC 34 Opt NZ Vis Chk
Use
0
Const Check whether there is a nozzle in the ANC pocket
before placing the nozzle:
0: Not Checked
1: checked
64 Opt ANC Shutter
Use
50
Const Use the function minimizing the ANC shutter Open/Close
movement when getting a nozzle
0: Not Checked
1: checked
Module No Name Div Value Unit Description
13-65
Software
Vacuum 60 Opt Vac Dump Saver
Time Out
Use
300 sec
When the head vacuum is not used in the IDLE mode,
shut off the vacuum pump after a given period of time.
66 Opt Pick Vac Chk
Use
19
msec 0: The routine to check whether the part is picked up is
not used when picking up a part
1: The routine to check whether the part is picked up is
used when picking up a part
safety 47 Opt Area Sensor
Use
0
Const 0: Not Checked
1: Area Sensor used
Align /
Mount
50 Opt MFOV No Z Up
Use
0
Const 0: The Z-axis moves up/down during XY movement for
split recognition
1: The Z-axis does not move during XY movement for
split recognition
71 Opt HRS Vision
Use
0
Const 0: HRS function not used
1: HRS function used
Module No Name Div Value Unit Description
13-66
Fast & Flexible Chip Shooter DECAN F2 Service Manual
13.5. Debug Constant
Module No Name
구분
Value
단위
Description
ANC 50 Ignore Noz Chk
Sensor
Use
00,1
When the nozzle check sensor has a problem, if this
value is set to 1, the sensor is not checked.
58 ANC Speed Option
Use
1
Const LookAhead function setup
0: Not Setting
1: Setting
Align /
Mount
30 Support Grab And
Move
Use
1
Determine whether to start to move immediately after
grabbing when using the fix camera:
0: Move after recognition
1: Move after grabbing
60 Support Smart Profile
Use
0
Const Smart Profile Algorithm
62 Fly Const Time
Use
25 msec
Time of constant speed for part recognition by fly camera
63 Fly Decstart Time
Use
90 msec
Time to start speed reduction for part recognition by fly
camera
69 Support Smart Seq
Use
1297
Const Smart Seq Algorithm
