13-14 Fast & Flexible Chip Shooter DECAN F2 Service Manual [Directory] MMI_EXE=Smart SM.exe MMI execution file name MMI_INI=SmartS M.ini MMI ini file name MMI_CLASS=Sm artQ MMI Name by which the vision system identif…

100%1 / 604
13-13
Software
[TARGET] BitmapSimul=1
Developer
GrabberType=44 Designate the
vision board
type and
number
4:Mega Board,
2:SAMC-62 Board
GrabberTypeFID
=0
Fiducial
camera board
type
Applicable only to
machines with a
separate vision board
for the SLM and
fiducial cameras
DebugWindowSh
ow=0
Whether to
execute the
Vision Log
Window
Option applied when
loading a program
Interrupt=0
Developer
SendVMEInterru
pt=0
Developer
MxCameraType=
4
Developer
MxCameraTypeF
ID=0
Developer
WindowTitle=SM
VisionQ
Title of the
Vision Window
Name identifying the
Vision Window in the
MMI
Real=1 Classify the
machine and
PC
Machine=1, PC=0
DPVersion=1
Developer
NoMMI=0
Developer
Classification
Item and Default
Value
Description
Remarks
13-14
Fast & Flexible Chip Shooter DECAN F2 Service Manual
[Directory] MMI_EXE=Smart
SM.exe
MMI execution
file name
MMI_INI=SmartS
M.ini
MMI ini file
name
MMI_CLASS=Sm
artQ MMI
Name by which
the vision
system
identifies the
MMI window
LogDir=C:\Smart
SM\log\
Log file
directory
MMI_ROOT=C:\S
martSM\Bin\
MMI execution
file directory
SysDir=C:\Smart
SM\System\
System file
directory
System file
directory
Temporary file
directory
[MsgDriverType] Ethernet=1 RT interface
method
(network)
MsgDriverIniFile=
C:\SmartSM\Bin\
MsgDriverType.in
i
Network setup
file name
Classification
Item and Default
Value
Description
Remarks
13-15
Software
[SECTION_GANTR
Y]
IsSection0=1 Applicable to
front/rear
machine or 1G
machine
NumGantryInSec
tion0=2
Check whether
the machine
has four
gantries.
IsSection1=0 Check whether
the machine
has four
gantries.
NumGantryInSec
tion1=2
Check whether
the machine
has four
gantries.
[DISPLAY_CAMER
A_CHAIN]
SingleView=1 Whether to
divide the
vision window
into several
windows
CamsInGantry0=
0_1_10
Representative
camera of the
1F front gantry
CamsInGantry1=
16_17_26
Representative
camera of the
1R front gantry
CamsInGantry2=
32_33_42
Representative
camera of the
2F front gantry
CamsInGantry3=
48_49_58
Representative
camera of the
2R front gantry
Classification
Item and Default
Value
Description
Remarks
