13-12
Fast & Flexible Chip Shooter DECAN F2 Service Manual
11) [Gamma] category
Table13.1 Description of Vision.ini
Item
Default
Value
Description Remarks
Use 0 Communicates with the
Production Management System
(Gamma) of Samsung
Electronics
0 : Not use
1 : Use
Item
Default
Value
Description Remarks
UserSelectCo
nfigure
0 Enables the conveyor
configuration type selection
window when booting the MMI
0 : Not use
1 : Use
Once the MMI
booting is
completed, the
corresponding value
is restored to 0.
AutoConfigure
Change
0 Selects Shuttle-Dual-Shuttle
automatically during MMI booting
regardless of existing conveyor
configuration
0 : Not use
1 : Use
Once the MMI
booting is
completed, the
corresponding value
is restored to 0.
Classification
Item and Default
Value
Description
Remarks
[MACHINE_TYPE] MACHINE=412 Machine Type The machine type
must correspond to
the machine model.
13-13
Software
[TARGET] BitmapSimul=1
Developer
GrabberType=44 Designate the
vision board
type and
number
4:Mega Board,
2:SAMC-62 Board
GrabberTypeFID
=0
Fiducial
camera board
type
Applicable only to
machines with a
separate vision board
for the SLM and
fiducial cameras
DebugWindowSh
ow=0
Whether to
execute the
Vision Log
Window
Option applied when
loading a program
Interrupt=0
Developer
SendVMEInterru
pt=0
Developer
MxCameraType=
4
Developer
MxCameraTypeF
ID=0
Developer
WindowTitle=SM
VisionQ
Title of the
Vision Window
Name identifying the
Vision Window in the
MMI
Real=1 Classify the
machine and
PC
Machine=1, PC=0
DPVersion=1
Developer
NoMMI=0
Developer
Classification
Item and Default
Value
Description
Remarks
13-14
Fast & Flexible Chip Shooter DECAN F2 Service Manual
[Directory] MMI_EXE=Smart
SM.exe
MMI execution
file name
MMI_INI=SmartS
M.ini
MMI ini file
name
MMI_CLASS=Sm
artQ MMI
Name by which
the vision
system
identifies the
MMI window
LogDir=C:\Smart
SM\log\
Log file
directory
MMI_ROOT=C:\S
martSM\Bin\
MMI execution
file directory
SysDir=C:\Smart
SM\System\
System file
directory
System file
directory
Temporary file
directory
[MsgDriverType] Ethernet=1 RT interface
method
(network)
MsgDriverIniFile=
C:\SmartSM\Bin\
MsgDriverType.in
i
Network setup
file name
Classification
Item and Default
Value
Description
Remarks
