13-9 Software ShowPartDes cription 1 Determines whether t o show the Part Description in the S tep window 0 : Hides Description column 1 : Shows the Description column Allows the Description columns which are not relativ…
13-8
Fast & Flexible Chip Shooter DECAN F2 Service Manual
visFrame SMVisi
on
Name of the Vision program in
the window
(Name of an application program)
In order for the MMI
to handle the Vision
program
PlaceZValue 0 Z offset of placement on a board -500 ~ 500
LogSize 3 Limits the job history log file size
in the MMI
1 : 10MB
2 : 20MB
3 : 30MB
4 : 40MB
5 : 50MB
LogTime
2
Limits the job history log file
storage period in the MMI
1 : 1year
2 : 2year
3 : 3year
4 : 4year
5 : 5year
BadmarkTran
sfer
2 Transmits the bad mark
information to the next machine
0 : Not use
2 : Use
ScanEyeDir C:\Sma
rtSM\P
CB\rep
ort_bb.t
xt
Basic folder for the sharing of the
file name and file in which bad
mark information is contained
BackLightNoz
zle
0 Whether to use the Back Light
Nozzle
0 : Not use (Only the Front Light
is used)
1 : Use (Both the Front Light and
Back Light are used)
If this value is 1, the
type of illumination
to be used when
performing aligning
in the Part Edit
window must be
determined. (Front /
Back)
Item
Default
Value
Description Remarks
13-9
Software
ShowPartDes
cription
1 Determines whether to show the
Part Description in the Step
window
0 : Hides Description column
1 : Shows the Description column
Allows the
Description columns
which are not
relatively important
to be hidden due to
confined Step
window.
SECS 0 Whether to enable the SECS/
GEM communication
0 : Disable
1 : Enable
AuthorityLimit 0 When changing the Operator
level, enables/disables the
function to limit the applying time
of the changed level by default
0 : Disable
1 : Enable
Even though this is
set to Disable by
default, it can be
enabled again by
checking
UseAccessLimit in
the Access Limit
window.
AuthorityLimit
Time
5 Sets the applying time of the
AuthorityLimit function when
using it (Minute unit)
UseRank 0 Displays/removes the Rank
column in the Feeder Base
window
0 : Remove
1 : Display
It can be set again in
the Sys.Setup >
Pref. > General tab
Tele met ryAut o
Save
1 Saves the Telemetry
automatically when an error
occurs during RT operation
0 : Not use
1 : Use
Item
Default
Value
Description Remarks
13-10
Fast & Flexible Chip Shooter DECAN F2 Service Manual
6) [SEC] category
7) [PM] category
EditConveyor 0 Displays the UI that can set the
position coordinate (X) and
length of the stations in the MMI
Conveyor Calibration window
0 : Not use
1 : Use
Sys.Setup > Calib. >
Conveyor
Calibration
UseInnerLight 1 Enables/disables the inner
illumination related controls in the
MMI
0 : Disable
1 : Enable
The related UI is
displayed to allow
the adjustment/
setup of the inner
illumination in the
MMI.
Item
Default
Value
Description Remarks
ProdVacChec
k
1 Displays the aggregate data of
the Post Pickup and PrePlace in
the Production Information
window
0 : Not use
1 : Use
Ref. Ref same more
than one Step1:
(Reference) overlap.
If a person is used
Item
Default
Value
Description Remarks
PMM 1 Enables the function for
interlocking between the MMI
PMManager
0 : Disable
1 : Enable
When enabled, this
can run the
PMManager and the
button on which the
alarm function of the
PMManager is
indicated in color is
displayed in the
Utility tab.
Item
Default
Value
Description Remarks
