1-4 Fast & Flexible Chip Shoo ter DECAN F2 Service Manual 1.1.2.2. Fiducial Vision 1.1.2.3. Flying vision ITEM Sp ecifications Function Component teaching, Fiducial inspection Camera type Analog 640 X 480 pixel, C-mo…
1-3
Specifications
1.1.2. Detail Specification
1.1.2.1. General
ITEM
Specifications
Tack time Under optimum condition 79,000 cph, chip1608
(0.046 seconds/component)
Miss pick ratio
Less than 1000 ppm, Chip1005
Less than 2000 ppm, Chip0603
Less than 4000 ppm, Chip0402
Flying vision MEGA FOV 24mm Chip : 0402~□16mm
IC, Connector : □16 mm and smaller, Lead pitch of more than 0.4 mm
BGA, CSP : □16 mm and smaller, Ball pitch of more than 0.5 mm
Maximum height 12mm
Placement Accuracy Chip 0402 : X,Y : ±0.05 mm, θ : ±5.00 °, Cpk≥1.0
Chip 0603 : X,Y : ±0.08 mm, θ : ±5.00 °, Cpk≥1.0
Chip 1005 : X,Y : ±0.10 mm, θ : ±5.00 °, Cpk≥1.0
Lead IC 0.4 P : X,Y : ±0.05 mm, θ : ±0.20 °, Cpk≥1.0
CSP Ball 0.4 Pitch : X,Y : ±0.05 mm, θ : ±0.30 °, Cpk≥1.0
1-4
Fast & Flexible Chip Shooter DECAN F2 Service Manual
1.1.2.2. Fiducial Vision
1.1.2.3. Flying vision
ITEM
Specifications
Function
Component teaching, Fiducial inspection
Camera type Analog 640 X 480 pixel, C-mount
Configuration 1 Camera@Head FOV 7.5 mm x 1 Set x 2 Gantry
2 Camera@Head
FOV 7.5 mm x 2 Set x 2 Gantry
Illumination
Light source
LED
Light adjustment 16 Level
Light control
Programmable, 2종(Outer light, Coaxial light)
ITEM
Specifications
Function Component inspection
Mega Camera type Analog 1360 X 1040 pixel, C-mount
Configuration FDV 24 mm × 5 EA x 2 Gantry
1-5
Specifications
1.1.2.4. Vision Board
Illumination Light source LED
Light adjustment 16 Level
Light control Programmable, 3 Type (Outer light, Side light, Coaxial light)
ITEM
Specifications
ITEM
Specifications
Board Fly camera Analog camera grabber : 1360 x 1040
