1-16
Fast & Flexible Chip Shooter DECAN F2 Service Manual
1.1.2.14. Safety Device
Operation panel Front : Start/Stop/Reset/Feeder change/Teaching box
Rear : Start/Stop/Reset/Feeder change/Teaching box
ITEM
Specifications
ITEM
Specifications
Main Breaker Rated short circuit breaking capacity :
25KA (GV2-ME22)
Emergency Switch Mushroom type push button switch
Door S/W Key interlock switch
Area sensor AUTONICS BWP20-12
Feeder sensor Photo sensor
Safeguard override switch Key select switch
Front and rear operation selection switch Key select switch
1-17
Specifications
1.1.2.15. MMI
1.1.2.16. SMEMA
ITEM
Specifications
language Korean, English, Chinese
Communication LAN
OS
Windows XP
ITEM
Specifications
From Next
M/C
Busy Input (In) Pin #1 : (+) Input signal
Pin #2 : (-)
Board Available Input (Out) Pin #3 : Contact output
Pin #4 : Contact output
Connector AMP 206043-1
AMP 206044-1
1-18
Fast & Flexible Chip Shooter DECAN F2 Service Manual
From Previous
M/C
Busy output (Out) Pin #1 : Contact output
Pin #2 : Contact output
Board available input (In) Pin #3 : (+) Input signal
Pin #4 : (-)
Connector AMP 206043-1
AMP 206044-1
ITEM
Specifications
