Fast & Flexible Chip Shooter DECAN F2 Service Manual
HW 17 Use UPS
Use
0
Const 0: UPS not used. 1: UPS used
18 CE Type
Use
0
Const 0: CE not applied
1: CE applied
XY Move 40 Sys Delay XY1
Use
20
msec Delay used for general XY movement
41 Sys Delay XY2
Use
0
msec Delay used for XY movement for part pickup
42 Sys Delay XY3
Use
8
msec Delay (polling) used for XY movement for part placement
43 Sys Delay XY4
Use
40
msec Delay used for XY movement requiring high precision
44 Sys Backlash XY
Use
5um
Zone used for the XY backlash prevention algorithm
Z Move 45 Sys Delay Z1
Use
0
msec Delay used for general Z movement
48 Sys Delay Z4
Use
20
msec Delay used for Z movement requiring high precision
81 Escape Z Fast
Use
21000 um
In the case of the FLY_SS cycle, this refers to the Z-axis
position (between 6000 ~ 45000) at which the mirror
starts to come in after the Z-axis has picked up a part.
82 Escape Z Mnt Fast
Use
2500 um
In the case of the FLY_SS cycle, this refers to the Z-axis
height (between 1000 ~ 6000) to which the XY can move
when it moves up after the Z-axis has performed part
placement.
Values other than these will be processed as 8000.
Module No Name Div Value Unit Description
13-55
Software
R Move 50 Sys Delay R1
Use
50
msec Delay used for general R movement
51 Sys Delay R2
Use
50
msec Delay used for R movement for part pickup
52 Sys Delay R3
Use
15
msec Delay used for R movement for part placement
53 Sys Delay R4
Use
50
msec Delay used for R movement requiring high precision
54 Sys Backlash R
Use
1500
msec Zone used for the R backlash prevention algorithm
Mir Move
55 Sys Delay M1
Use
0
msec In the case of the FLY_SS cycle, this refers to the delay
when the mirror closes.
58 Sys Delay M4
Use
0
msec Delay when the mirror closes
80 Escape M Fast
Use
170000 mdeg
In the case of the FLY_SS Cycle, this refers to the mirror
angle (between 80000 ~ 175000) at which the Z-axis
starts to move when the mirror is opened.
Values other than these will be processed as 8000.
Side
Down
60 Head Side Dn Time
Use
0
msec Minimum time required to operate the side illumination of
the head
61 Head Side Dn
Timeout
Use
500
msec Time-out when operating the side illumination of the head
특정기능
86
Twin Servo Skew Dist
Use
200 um
Allowable skew error of the Y1/Y2
Module No Name Div Value Unit Description
13-56
Fast & Flexible Chip Shooter DECAN F2 Service Manual
Pick up 84 Use Fast Pick up
Use
1
Const 0: Fast PickUp not used
1: Fast PickUp used
95 Pick Teach xy Method
Use
0
Const Set the function for Pick-Up Position XY Offset correction
during automatic placement.
In order to reflect the corrected offset, the No. 31 Debug
Constant (TAPE_PICK_OFFSET_WEIGHT) must be set
to 1.
0: Not used.
1: Performed when Part Retry Out occurs.
2: Corrected immediately before the set Part Retry Out
Count. When it is NG even after the correction, the
machine stops.
3: Always performed before picking up s part (applicable
to fine parts less than 0402).
Module No Name Div Value Unit Description
