14-28 Fast & Flexible Chip Shooter DECAN F2 Service Manual 6) When assembling a board, set the DIP sw itch as shown in the following figure. 7) Referring to the following figure , and then connect th e connecto r .

14-27

Board

3) Remove the rear cover.

4) Unscrew the fixing bolts(4-M3*6) securing the Safety Control Board using a wrench

and remove it.

5) Assemble in the Rear Electric Panel a new Board.

Ref The part number of the new Board is J91741087A.

14-28

Fast & Flexible Chip Shooter DECAN F2 Service Manual

6) When assembling a board, set the DIP switch as shown in the following figure.

7) Referring to the following figure, and then connect the connector.

14-29

Board

14.7. 16 Axis Board

14.7.1. Required Tools

 Crosshead (Phillips) screwdriver and flathead screwdriver

 T Wrench or Hex Wrench

 Nipper (Remove the Cable Tie)

14.7.2. 16 Axis Board Replacement Procedure

1) Close the PC as usual and turn off the main switch at the front of the machine.

2) Turn off the main power supply to the machine.

Warning Before servicing the machine, turn off the power switch

located at the front bottom as well as the main circuit

breaker at the rear bottom of the machine. Otherwise,

serious personal injury may occur. Perform servicing with

the power supply to the machine cut off without fail.

Warning Be sure to wear anti-electrostatic gloves when servicing the

machine.
