13-61
Software
Feeder
23 Opt Stick Link
Use
0
Const Whether to use the Auto Link of the part supplied to a
stick feeder
0: AUTO LINK
1: NOT LINK
59 Opt Tape Clamp
Use
8
Const 0: Not used
1: Feeding시 Check
1: Checked when Feeding
4: Checked when downloading a PCB
8: Feeder not clamped is skipped
62 Opt Tape Index
Use
1
Const 0: Not checked
1: Checked during feeding and treated as an emergency
error when timeout occurs
65 Opt Tape Link
Otherside
Use
0
Const 0: Not used
1: Used
Module No Name Div Value Unit Description
13-62
Fast & Flexible Chip Shooter DECAN F2 Service Manual
Fiducial 11 Opt Bad First Use 0
Const 0: Fiducial mark first
1: Bad markfirst
69 Opt Man Fid Assist
Enable
Use 0
Const 0:Normal
3: Deletes the screen for the manual fiducial ENT
function and Retry function
72 Opt Fid Dist Chk
Use
1
Const 0: The function to check the distance between fiducials is
not used
1: Generates an error when the distance between
fiducials exceeds the allowable value (1mm)
Tray 12 Opt Tray Timel
Use
0
Const 0: Pallet Change to basic. Stable pallet change
1: Fast pallet change
2: Pallet change as fast as possible
16 Opt Tray Nonstop
Use
0
Const For setup of the FW12M/S tray feeder as non-stop or not.
When the non-stop function of another model is used, it
must be set to ‘0’.
0: Tray Non Stop not used
1: Used
24 Opt Tray Link
Use
0
Const Whether to use the Auto Link of the tray part
0: AUTO LINK
1: NOT LINK
Module No Name Div Value Unit Description
13-63
Software
편의사항
25
Opt Home Method
Use
15
Const 1: Not performed newly if XY homing is performed before
during actual placement
2 : Not performed newly if Z homing is performed before
actual placement
4 : Not performed newly if R homing is performed before
actual placement
8 : Not performed newly if MIR homing is performed
during actual placement
16 : Not performed newly if BUT homing is performed
before actual placement
33
Opt Lts Method
Use
0
0: Not used
1: Used
41
Opt Light Saver Time
Out
Use
300
Const Refers to the function that turns off all illuminations after
the time set here to protect the illumination
Conveyor 19 Opt Quicklload
Use
1
Const 1: Quick Work->Use of Out Sensor
16: Sync Move (Quick Load previous)
99 CV Config User Sel
Use
1
Const 0: CV Not selected
1: CV Selected
Module No Name Div Value Unit Description
