13-7
Software
5) [Option] category
Item
Default
Value
Description Remarks
ManufactLog
1
Creates a log for the job
information history
0 : Not use
1 : Use
This function can be
used only when the
Pd.Info function of
the Utility is also set
to 1.
Welcome
0
Determines whether to use the
Welcome window after finishing
the MMI booting.
0 : Not use
1 : Use
Provides the
recently used PCB
file information and
PCB file selection
method visually.
AccessLimit
1
Sets the default user level after
booting the MMI
0 : Set to the Manager level
1 : Set to the Operator level
When making the
Manager level the
default by setting
this value to 0, it
cannot be changed
to Operator or
Developer level.
IQFEEDER 1, 2 Sets the IQ Feeder operation
mode.
0 : IT function Not used
1 : Full IT mode (IT System used)
2 : Use some IT (Electrically
driven feeder can be used by
default)
The default value is
determined by the
installer when
selecting the SW
package.
LotTracking
0
LOT Tracking function
0 : Not use
2 : Use
In order to use the
barcode recognition
function, both the
IQFEEDER and
LOTTracking must
be set to 2.
UseSingleMo
nitor
1
Whether to use a single monitor
0 : Use multi monitor
1 : Use single monitor
In order to set the
default position of
the Vision window in
the monitor
13-8
Fast & Flexible Chip Shooter DECAN F2 Service Manual
visFrame SMVisi
on
Name of the Vision program in
the window
(Name of an application program)
In order for the MMI
to handle the Vision
program
PlaceZValue 0 Z offset of placement on a board -500 ~ 500
LogSize 3 Limits the job history log file size
in the MMI
1 : 10MB
2 : 20MB
3 : 30MB
4 : 40MB
5 : 50MB
LogTime
2
Limits the job history log file
storage period in the MMI
1 : 1year
2 : 2year
3 : 3year
4 : 4year
5 : 5year
BadmarkTran
sfer
2 Transmits the bad mark
information to the next machine
0 : Not use
2 : Use
ScanEyeDir C:\Sma
rtSM\P
CB\rep
ort_bb.t
xt
Basic folder for the sharing of the
file name and file in which bad
mark information is contained
BackLightNoz
zle
0 Whether to use the Back Light
Nozzle
0 : Not use (Only the Front Light
is used)
1 : Use (Both the Front Light and
Back Light are used)
If this value is 1, the
type of illumination
to be used when
performing aligning
in the Part Edit
window must be
determined. (Front /
Back)
Item
Default
Value
Description Remarks
13-9
Software
ShowPartDes
cription
1 Determines whether to show the
Part Description in the Step
window
0 : Hides Description column
1 : Shows the Description column
Allows the
Description columns
which are not
relatively important
to be hidden due to
confined Step
window.
SECS 0 Whether to enable the SECS/
GEM communication
0 : Disable
1 : Enable
AuthorityLimit 0 When changing the Operator
level, enables/disables the
function to limit the applying time
of the changed level by default
0 : Disable
1 : Enable
Even though this is
set to Disable by
default, it can be
enabled again by
checking
UseAccessLimit in
the Access Limit
window.
AuthorityLimit
Time
5 Sets the applying time of the
AuthorityLimit function when
using it (Minute unit)
UseRank 0 Displays/removes the Rank
column in the Feeder Base
window
0 : Remove
1 : Display
It can be set again in
the Sys.Setup >
Pref. > General tab
Tele met ryAut o
Save
1 Saves the Telemetry
automatically when an error
occurs during RT operation
0 : Not use
1 : Use
Item
Default
Value
Description Remarks
