13-10 Fast & Flexible Chip Shooter DECAN F2 Service Manual 6) [SEC] category 7) [PM] category EditConveyor 0 Displays the UI that can set the position coordinate (X) and length of the sta tions in the MMI Conveyor Ca…
13-9
Software
ShowPartDes
cription
1 Determines whether to show the
Part Description in the Step
window
0 : Hides Description column
1 : Shows the Description column
Allows the
Description columns
which are not
relatively important
to be hidden due to
confined Step
window.
SECS 0 Whether to enable the SECS/
GEM communication
0 : Disable
1 : Enable
AuthorityLimit 0 When changing the Operator
level, enables/disables the
function to limit the applying time
of the changed level by default
0 : Disable
1 : Enable
Even though this is
set to Disable by
default, it can be
enabled again by
checking
UseAccessLimit in
the Access Limit
window.
AuthorityLimit
Time
5 Sets the applying time of the
AuthorityLimit function when
using it (Minute unit)
UseRank 0 Displays/removes the Rank
column in the Feeder Base
window
0 : Remove
1 : Display
It can be set again in
the Sys.Setup >
Pref. > General tab
Tele met ryAut o
Save
1 Saves the Telemetry
automatically when an error
occurs during RT operation
0 : Not use
1 : Use
Item
Default
Value
Description Remarks
13-10
Fast & Flexible Chip Shooter DECAN F2 Service Manual
6) [SEC] category
7) [PM] category
EditConveyor 0 Displays the UI that can set the
position coordinate (X) and
length of the stations in the MMI
Conveyor Calibration window
0 : Not use
1 : Use
Sys.Setup > Calib. >
Conveyor
Calibration
UseInnerLight 1 Enables/disables the inner
illumination related controls in the
MMI
0 : Disable
1 : Enable
The related UI is
displayed to allow
the adjustment/
setup of the inner
illumination in the
MMI.
Item
Default
Value
Description Remarks
ProdVacChec
k
1 Displays the aggregate data of
the Post Pickup and PrePlace in
the Production Information
window
0 : Not use
1 : Use
Ref. Ref same more
than one Step1:
(Reference) overlap.
If a person is used
Item
Default
Value
Description Remarks
PMM 1 Enables the function for
interlocking between the MMI
PMManager
0 : Disable
1 : Enable
When enabled, this
can run the
PMManager and the
button on which the
alarm function of the
PMManager is
indicated in color is
displayed in the
Utility tab.
Item
Default
Value
Description Remarks
13-11
Software
8) [PRODUCT OPTION] category
Presets the default options in the Option Setting Page in the Product window
Sets the Real Info function provided by the Product Monitor Page in the Product
window
(The RealInfo_Show must be set to 1 and at the same time the function works only at
the Developer level.)
9) [MsgDriverType] category
10) [Gamma] category
PmAutoRun 1 Runs the PMManager
automatically when booting the
MMI
0 : Not use
1 : Use
PmDir C:\Sma
rtSM\bi
n
Folder containing the PMManger
execution file
PmExe PMMan
ager.ex
e
Name of the PMManger
execution file
Item
Default
Value
Description Remarks
MsgDriverIniF
ile
C:\Sma
rtSM\Bi
n\MsgD
riverTyp
e.ini
Name and position of the file in
which the IP and communication
port of the MMI, RT and Vision is
set
Item
Default
Value
Description Remarks
