13-7 Software 5) [Option] category Item Default Va l u e Description Remarks ManufactLog 1 Creates a log for the job information history 0 : Not use 1 : Use This function can be used only when the Pd.Info function of the…
13-6
Fast & Flexible Chip Shooter DECAN F2 Service Manual
3) [Optimizer] category – Do not edit
Basic information necessary for the execution of the optimization algorithm of the
optimizer
Required time or time weight factor for each of the internal operations of the machine
Whether to use the optimizer and Vision by head type
4) [ETC] category
TempDir C:\Sma
rtSM\te
mp
Temporary folder that is used by
SW modules including MMI for
various purposes during
operation
MMI<->Optimizer
Communication This
folder includes
related files and
placement accuracy
self test results file,
etc.
PdInfoDir C:\Sma
rtSM\P
DInfo
Folder in which the job status
history is saved in log file format
Item
Default
Value
Description Remarks
CheckWarnin
g
0
Displays a warning against
Refduplication and skip setup
when downloading the setup
information to the RT.
0 : Not use
1 : Use
Ref. (Reference)
duplicated : More
than one of the
same Ref. name
was used for the
Step.
UpdatePart
0
Synchronizes the part in a PCB
file and the content in the Part DB
when opening a PCB file.
0 : Clear the function
1 : Ignore the part information in
the PCB file and update it with
the content in the Part DB
2 : Update the part information of
the PCB file to the Part DB
3 : Same as #1 above
When operated as a
Full IT option, notify
the change in the
part information to
the IT system.
Item
Default
Value
Description Remarks
13-7
Software
5) [Option] category
Item
Default
Value
Description Remarks
ManufactLog
1
Creates a log for the job
information history
0 : Not use
1 : Use
This function can be
used only when the
Pd.Info function of
the Utility is also set
to 1.
Welcome
0
Determines whether to use the
Welcome window after finishing
the MMI booting.
0 : Not use
1 : Use
Provides the
recently used PCB
file information and
PCB file selection
method visually.
AccessLimit
1
Sets the default user level after
booting the MMI
0 : Set to the Manager level
1 : Set to the Operator level
When making the
Manager level the
default by setting
this value to 0, it
cannot be changed
to Operator or
Developer level.
IQFEEDER 1, 2 Sets the IQ Feeder operation
mode.
0 : IT function Not used
1 : Full IT mode (IT System used)
2 : Use some IT (Electrically
driven feeder can be used by
default)
The default value is
determined by the
installer when
selecting the SW
package.
LotTracking
0
LOT Tracking function
0 : Not use
2 : Use
In order to use the
barcode recognition
function, both the
IQFEEDER and
LOTTracking must
be set to 2.
UseSingleMo
nitor
1
Whether to use a single monitor
0 : Use multi monitor
1 : Use single monitor
In order to set the
default position of
the Vision window in
the monitor
13-8
Fast & Flexible Chip Shooter DECAN F2 Service Manual
visFrame SMVisi
on
Name of the Vision program in
the window
(Name of an application program)
In order for the MMI
to handle the Vision
program
PlaceZValue 0 Z offset of placement on a board -500 ~ 500
LogSize 3 Limits the job history log file size
in the MMI
1 : 10MB
2 : 20MB
3 : 30MB
4 : 40MB
5 : 50MB
LogTime
2
Limits the job history log file
storage period in the MMI
1 : 1year
2 : 2year
3 : 3year
4 : 4year
5 : 5year
BadmarkTran
sfer
2 Transmits the bad mark
information to the next machine
0 : Not use
2 : Use
ScanEyeDir C:\Sma
rtSM\P
CB\rep
ort_bb.t
xt
Basic folder for the sharing of the
file name and file in which bad
mark information is contained
BackLightNoz
zle
0 Whether to use the Back Light
Nozzle
0 : Not use (Only the Front Light
is used)
1 : Use (Both the Front Light and
Back Light are used)
If this value is 1, the
type of illumination
to be used when
performing aligning
in the Part Edit
window must be
determined. (Front /
Back)
Item
Default
Value
Description Remarks
