13-60
Fast & Flexible Chip Shooter DECAN F2 Service Manual
Feeder 10 Opt IQ Feeder
Use
0
Const 0 : IT Feeder not used
1 : Front IT Feeder used
16 : Rear IT Feeder used
17 : Front and rear IT Feeder used
20 Opt Feed Over
Use
34
Const How to use a Feeder Unlock Sensor.
>> D0-D3 : Front D4-D7 : Rear
0 : No Check(NO) 1 : Check(CH) 2 : INT Check(INT)
Value: Front, rear
0 : NO, NO
1 : CH, NO
2 : CH-INT, NO
16 : NO, CH
17 : CH, CH
18 : CH-INT, CH
32 : NO, CH-INT
33 : CH, CH-INT
34 : CH-INT, CH-INT
22 Opt Tape Link
Use
0
Const Whether to use the Auto Link of the part supplied to a
tape feeder.
0: AUTO LINK
1: NOT LINK
Module No Name Div Value Unit Description
13-61
Software
Feeder
23 Opt Stick Link
Use
0
Const Whether to use the Auto Link of the part supplied to a
stick feeder
0: AUTO LINK
1: NOT LINK
59 Opt Tape Clamp
Use
8
Const 0: Not used
1: Feeding시 Check
1: Checked when Feeding
4: Checked when downloading a PCB
8: Feeder not clamped is skipped
62 Opt Tape Index
Use
1
Const 0: Not checked
1: Checked during feeding and treated as an emergency
error when timeout occurs
65 Opt Tape Link
Otherside
Use
0
Const 0: Not used
1: Used
Module No Name Div Value Unit Description
13-62
Fast & Flexible Chip Shooter DECAN F2 Service Manual
Fiducial 11 Opt Bad First Use 0
Const 0: Fiducial mark first
1: Bad markfirst
69 Opt Man Fid Assist
Enable
Use 0
Const 0:Normal
3: Deletes the screen for the manual fiducial ENT
function and Retry function
72 Opt Fid Dist Chk
Use
1
Const 0: The function to check the distance between fiducials is
not used
1: Generates an error when the distance between
fiducials exceeds the allowable value (1mm)
Tray 12 Opt Tray Timel
Use
0
Const 0: Pallet Change to basic. Stable pallet change
1: Fast pallet change
2: Pallet change as fast as possible
16 Opt Tray Nonstop
Use
0
Const For setup of the FW12M/S tray feeder as non-stop or not.
When the non-stop function of another model is used, it
must be set to ‘0’.
0: Tray Non Stop not used
1: Used
24 Opt Tray Link
Use
0
Const Whether to use the Auto Link of the tray part
0: AUTO LINK
1: NOT LINK
Module No Name Div Value Unit Description
