11-6 Fast & Flexible Chip Shoo ter DECAN F2 Service Manual
11-5
Vacuum
11-6
Fast & Flexible Chip Shooter DECAN F2 Service Manual
11-7
Vacuum
11.2. Vacuum Pump
11.2.1. Required Tools
Crosshead (Phillips) screwdriver and flathead screwdriver
T Wrench or Hex Wrench
11.2.2. Vacuum Pump
11.2.3. Vacuum Pump Replacement Procedure
1) Close the PC as usual and turn off the main switch at the front of the machine.
2) Turn off the main power supply to the machine.
Warning Before servicing the machine, turn off the power switch
located at the front bottom as well as the main circuit
breaker at the rear bottom of the machine. Otherwise,
serious personal injury may occur. Perform servicing with
the power supply to the machine cut off without fail.
Warning Be sure to wear anti-electrostatic gloves when servicing the
machine.
