13-66
Fast & Flexible Chip Shooter DECAN F2 Service Manual
13.5. Debug Constant
Module No Name
구분
Value
단위
Description
ANC 50 Ignore Noz Chk
Sensor
Use
00,1
When the nozzle check sensor has a problem, if this
value is set to 1, the sensor is not checked.
58 ANC Speed Option
Use
1
Const LookAhead function setup
0: Not Setting
1: Setting
Align /
Mount
30 Support Grab And
Move
Use
1
Determine whether to start to move immediately after
grabbing when using the fix camera:
0: Move after recognition
1: Move after grabbing
60 Support Smart Profile
Use
0
Const Smart Profile Algorithm
62 Fly Const Time
Use
25 msec
Time of constant speed for part recognition by fly camera
63 Fly Decstart Time
Use
90 msec
Time to start speed reduction for part recognition by fly
camera
69 Support Smart Seq
Use
1297
Const Smart Seq Algorithm
13-67
Software
Pick Up 65 Pocket Teach Light
Out
Use
4
Const Set the inner illumination value of the fiducial camera that
is used for pocket teaching during automatic placement
66 Pocket Teach Light In
Use
0
Const Set the inner illumination value of the fiducial camera that
is used for pocket teaching during automatic placement
Module No Name
구분
Value
단위
Description
