13-3
Software
13.1.2. SmartSM.ini and Vision.ini File
At the time of delivery, the ‘ini’ file is set up as follows:
Description of SmartSM.ini
1) [Target] category
Item
Default
Value
Description Remarks
Real
1
Runs the RT and Vision
programs
0: Runs only the MMI
1: Runs all of the MMI, RT and
Vision programs
RtSim
0
RT Simulation Mode
0 : Runs in General mode
1 : Runs in Simulation mode
VisSim
0
Vision Simulation Mode
0 : Runs in General mode
1 : Runs in Simulation mode
13-4
Fast & Flexible Chip Shooter DECAN F2 Service Manual
MachineType 37 Name of SM Series models for
which SW is to be used
SM421: 15
SM411: 16
SM411F: 17
SM411S: 18
SM421P: 19
SM411FX: 20
SM431: 21
SM431L: 22
SHIELDCAN: 23
SHIELDCAN2: 24
SM451V: 30
SM451DH: 31
AP5: 50
V1: 200
SM471: 27
SM481: 28
SM482: 29
SM511(DECAN F2):
36
DECAN F2 SF: 37
RunVisFrame
1
Vision system check function
when running the MMI
0 : Checks whether the Vision is
executed normally
1 : Vision execution status not
checked
Even though this
value is set to 0, if
the Vision is
normally executed,
it is changed to 1.
Language
0
Language Selection
0 : English by default + Korean (I/
O description, RT message)
1 : English
2 : Chinese (Simplified)
3 : German
4 : Japanese
Regarding the
difference between
0 and 1, if 0 is
selected, the
messages set in the
ErrorMsg.dmb and
O_xxx.mdb are
displayed in Korean.
Item
Default
Value
Description Remarks
13-5
Software
2) [Directroy] category
ModuleDown
0
The machine that uses the VME
downloads the VME setup file to
the RT
1 : Downloads the VME
File to be
downloaded:
Vmectl.bin
Item
Default
Value
Description Remarks
InstallDrive C: Hard drive in which the operation
SW package is installed
HomeDir C:\Sma
rtSM
Folder in which the operation SW
package is installed
As a top level folder
of the SW package,
this includes db files
related to IO, Range
and ErrorMsg.
BinDir C:\Sma
rtSM\bi
n
Folder which includes executable
files and environment files of
various SW modules
PartDir C:\Sma
rtSM\pa
rtdb
Folder which includes the Part
Library
UPD.mdb and
STDUPD.mdb are
stored in this folder.
SystemDir C:\Sma
rtSM\sy
stem
Folder in which System setup
files are stored
Config-N.db,
machine.cfg,
System.stm,
Factroy.stm,
Device.mdb, etc.
are included.
PCBDir C:\Sma
rtSM\pc
b
Folder in which PCB files are
stored
This searches a
PCB file when
opening a PCB file
of the MMI.
LogDir C:\Sma
rtSM\lo
g
Folder in which log files created
by SW modules are stored
Download the target
file: Vmectl.bin
Item
Default
Value
Description Remarks
