17-42
Fast & Flexible Chip Shooter DECAN F2 Service Manual
Replace the Vacuum Generator.
Click System->Head->Set Nozzle Vacuum and set the nozzle vacuum again.
E0A05 Axis $A Error: Failed to find the Home Sensor
[Cause]
Defective contact due to the cable pin falling out
Defective position of the R-axis Home Sensor and auxiliary Home Sensor of the Head
#
Defective HEAD I/F board
Defective R-axis sensor cable
Short-circuit due to the burning of the general PW connection cable
Defective flat belt assembling
When the error “Failed to find the R-axis home” occurs, the feeder power connection
cable is disconnected.
[How to Check]
1. Check the assembling state of the corresponding axis cables.
2. Check the sensor position and its operation state (I/O operation).
3. Check the operation state of the Head I/F board.
[Measures]
Reassemble the connector pin of the Step Driver - Motor Power Cable.
Reassemble the set screw securing the Ball Spline of the Head #.
Replace the Head I/F Board.
Replace the R-axis Home Sensor.
Replace the general PW connection cable connected to the front main switch.
Replace the flat belt assembly.
Replace the feeder power connection cable.
E0A06 HEAD #3 moves too far out of the part placement point on the PCB
[Cause]
A problem occurred to the system data.
[How to Check]
Apply System Constants 96 and 97.
[Measures]
Change System Constants 96 and 97 (OPT_PART_ALIGN X,Y): Change X from 25
to 40 and Y from 40 to 60 and then perform calibration.
17-43
Troubleshooting
E0A07 [EMER] Axis # motor or origin position has been changed
[Cause]
Defective Connector Pin assembling
Motor origin position has been changed (environmental change)
Defective Z-axis motor
[How to Check]
1. Check the assembling state of the corresponding axis connector.
2. Check the motor origin and Z offset.
3. Check the motor operation state of the corresponding axis.
[Measures]
Reassemble the pin to the connector of the Z-axis board.
Calibrate the axis.
Replace the Z-axis and calibrate it.
E0A08 The Head $H picked the part $P at its edge in the feeder $F
[Cause]
A problem occurred to the system data [Calibration Data].
[How to Check]
Check the bending state of the Head Ball Spline.
[Measures]
Calibrate the head.
E0A09 Axis $A home calibration is not calibrated
[Cause]
Origin has been changed.
[How to Check]
Check the Z# home calibration.
[Measures]
Perform the Z# home calibration.
17-44
Fast & Flexible Chip Shooter DECAN F2 Service Manual
17.3.7. Even though the Ready On button is pressed, power is not supplied to the servo
motor
(E0B)
Cause Description Remarks
Even though the
Ready On
button is
pressed, power
is not supplied
to the servo
motor
Defective emergency switch connection E0B00
Infected by a virus E0B01
Defective PCI I/O Board contact
(Applicable only to SM series machines excluding the
DECAN F2, SLM, SM471 and SM48X.)
E0B02
Defective CAN Conveyor Board E0B03
Defective Safety Override Key contact E0B04
Defective relay contact of the Safety Control Board E0B05
Defective Step Driver E0B06
Defective CAN Master Board
(In the case of DECAN F2, SLM, SM471 and SM48X
machines, the Axis I/O Board is defective.)
E0B07
Defective contact of the PCI IO Board and Can Master Board
(Applicable only to SM series machines excluding the
DECAN F2, SLM, SM471 and SM48X.)
E0B08
Defective Magnetic Contactor E0B09
Defective SEDES Board
(Applicable only to SM series machines excluding the
DECAN F2, SLM, SM471 and SM48X.)
E0B0A
Servo motor
unable to
operate
Defective servo motor or servo motor drive E0B0B
Defective servo motor
Overload The motor is overloaded E0B0C
Under voltage,
over voltage
Check the drive and power supply line E0B0D
The machine
power supply
has no problem
but power is not
supplied to the
motor drive
The machine power supply has no problems but the power is
not supplied to the motor drive
E0B0E
Vibration and
resonance
A Vibration or resonance occurs to a specific axis motor E0B0D
Encoder related
alarm occurred
An Encoder related alarm occurred E0B10
Overvoltage
related alarm
Voltage is high E0B11
