1-13 Specifications 1.1.2.10. ANC 1.1.2.11. Nozzle ITEM Sp ecifications Ty p e 34 Hole nozzle hole +1 T ool hole Driving method Double acting air cylinder ITEM Sp ecifications Normal Nozzle CN020 O.D/I.D : Φ 0.50/ Φ 0.16…
1-12
Fast & Flexible Chip Shooter DECAN F2 Service Manual
1.1.2.9. Feeder Type
ITEM
Specifications
Tape Feeder
SMN-08 (8 mm) [By Function] IT / Non-IT, [Slot] 1 slot
SMN-08L (8 mm) [By Function] IT / Non-IT, [Slot] 2 slots
SMN-12 (12 mm) [By Function] IT / Non-IT, [Slot] 2 slots
SMN-16 (16 mm) [By Function] IT / Non-IT, [Slot] 2 slots
SMN-24 (24 mm) [By Function] IT / Non-IT, [Slot] 3 slots
SME-08 (8 mm) [By Function] IT [Slot] 1 slot
SME-08L (8 mm) [By Function] IT [Slot] 2 slot
SME-12 (12 mm) [By Function] IT [Slot] 2 slots
SME-16 (16 mm) [By Function] IT [Slot] 2 slots
SME-24 (24 mm) [By Function] IT [Slot] 3 slots
Vibration feeder FS-V-SM 4 Lane Feeding
Single tray feeder FW-1-SM(2B) For installation at the front and Rear, one set of tray is used (horizontal
feeding)
1-13
Specifications
1.1.2.10. ANC
1.1.2.11. Nozzle
ITEM
Specifications
Type
34 Hole nozzle hole +1 Tool hole
Driving method Double acting air cylinder
ITEM
Specifications
Normal Nozzle
CN020
O.D/I.D : Φ0.50/Φ0.16 mm, Small size hole
CN030
O.D/I.D : Φ0.6/Φ0.28 mm, Small size hole
CN040
O.D/I.D : Φ0.75/Φ0.38 mm, Small size hole
CN065
O.D/I.D : Φ1.2/Φ0.65 mm, Small size hole
CN140
O.D/I.D : Φ2.2/Φ1.4 mm, Small size hole
CN220
O.D/I.D : Φ3.6/Φ2.2 mm, Small size hole
CN400
O.D/I.D : Φ6.0/Φ4.0 mm, Small size hole
Rubber Nozzle
CN350R Rubber O.D /I.D : Φ3.5/Φ2.2/Φ1.3 mm, Small size hole
1-14
Fast & Flexible Chip Shooter DECAN F2 Service Manual
1.1.2.12. ETC
Calibration Nozzle
Glass O.D : Φ11.0 mm
ITEM
Specifications
ITEM
Specifications
Feeder Mechanism Air cylinder
Electric feeder
Feeder lock Front unlock detection sensor
Rear unlock detection sensor
Tape feeder No. of Interchangeable feeders : 120, 112stations
Attachment pitch : 15mm
Driving method : Built In air cylinder
Driving method : Built In electric power
Feeder base Front : 60 Slots
Rear : 60 Slots
Docking cart Front : 56 Slots
Rear : 56 Slots
Dump box Standard : L170 x W22 mm
