1-16 Fast & Flexible Chip Shoo ter DECAN F2 Service Manual 1.1.2.14. Safety Device Operation p anel Front : S tart/S top/Reset/Feeder chang e/T eaching box Rear : S tart/S top/Reset/Feeder change/T eaching box ITEM S…
1-15
Specifications
1.1.2.13. Control Unit
ITEM
Specifications
CPU/ MMI INTEL i7 (2.1GHz)
Memory 4G, DDR3
Monitor USB MEMORY/HDD
Input method
Monitor
Head Z axis : 20 axis, AC servo control
θ axis : 10 axis, Micro stepping control
S axis : 2 axis, AC servo control
XY
X axis : 2 axis, AC servo control
Y axis : 4 axis, AC servo control
Conveyor IN axis : 2 axis. Micro stepping control
Work axis : 2 axis. Micro stepping control
Out axis : 2 axis. Micro steeping control
Shuttle axis : 2 axis. Stepping servo control
Width axis : 4 axis. Stepping servo control
I/O Digital I/O : Max. 600 EA
Analog I/O : Max. 12 EA
1-16
Fast & Flexible Chip Shooter DECAN F2 Service Manual
1.1.2.14. Safety Device
Operation panel Front : Start/Stop/Reset/Feeder change/Teaching box
Rear : Start/Stop/Reset/Feeder change/Teaching box
ITEM
Specifications
ITEM
Specifications
Main Breaker Rated short circuit breaking capacity :
25KA (GV2-ME22)
Emergency Switch Mushroom type push button switch
Door S/W Key interlock switch
Area sensor AUTONICS BWP20-12
Feeder sensor Photo sensor
Safeguard override switch Key select switch
Front and rear operation selection switch Key select switch
1-17
Specifications
1.1.2.15. MMI
1.1.2.16. SMEMA
ITEM
Specifications
language Korean, English, Chinese
Communication LAN
OS
Windows XP
ITEM
Specifications
From Next
M/C
Busy Input (In) Pin #1 : (+) Input signal
Pin #2 : (-)
Board Available Input (Out) Pin #3 : Contact output
Pin #4 : Contact output
Connector AMP 206043-1
AMP 206044-1
