13-59
Software
Tow er
Lamp
9 Opt Sig Part Empty
Use
5
Const Used with a combination of the following setups:
1: Part Empty Warning (Yellow/Blue)
2: Part Empty Error (Red)
4: PCB Wait Warring (Yellow/Blue)
8: Bypass (Safe Guard) Warring (Yellow/Blue)
15 Opt Buzon off
Use
2
Const 0: Always Buzzer On when an error occurs
1: Always Buzzer Not On when an error occurs
2: Buzzer On selectively when an error occurs
61 Opt PCB Wait
Warning Time
Use
20
Const When waiting for a PCB in the Run state, change the
tower lamp signal after the given period of time
(according to the No. 9 system constant setup).
Module No Name Div Value Unit Description
13-60
Fast & Flexible Chip Shooter DECAN F2 Service Manual
Feeder 10 Opt IQ Feeder
Use
0
Const 0 : IT Feeder not used
1 : Front IT Feeder used
16 : Rear IT Feeder used
17 : Front and rear IT Feeder used
20 Opt Feed Over
Use
34
Const How to use a Feeder Unlock Sensor.
>> D0-D3 : Front D4-D7 : Rear
0 : No Check(NO) 1 : Check(CH) 2 : INT Check(INT)
Value: Front, rear
0 : NO, NO
1 : CH, NO
2 : CH-INT, NO
16 : NO, CH
17 : CH, CH
18 : CH-INT, CH
32 : NO, CH-INT
33 : CH, CH-INT
34 : CH-INT, CH-INT
22 Opt Tape Link
Use
0
Const Whether to use the Auto Link of the part supplied to a
tape feeder.
0: AUTO LINK
1: NOT LINK
Module No Name Div Value Unit Description
13-61
Software
Feeder
23 Opt Stick Link
Use
0
Const Whether to use the Auto Link of the part supplied to a
stick feeder
0: AUTO LINK
1: NOT LINK
59 Opt Tape Clamp
Use
8
Const 0: Not used
1: Feeding시 Check
1: Checked when Feeding
4: Checked when downloading a PCB
8: Feeder not clamped is skipped
62 Opt Tape Index
Use
1
Const 0: Not checked
1: Checked during feeding and treated as an emergency
error when timeout occurs
65 Opt Tape Link
Otherside
Use
0
Const 0: Not used
1: Used
Module No Name Div Value Unit Description
