Fast Smart Modular Mounter
RS-1/RS-1XL/RS-1R
INSTRUCTION MANUAL
Thank you for purchasing a product of our company.
CAUTION
In order to ensure safe use of RS-1 Series, be sure to read this Manual
before using the machine.
After reading this Manual, keep it at a fixed location so that it will be
available at any time.
Important
(1) No part of this document may be copied or reproduced without the prior
permission of JUKI Corporation. (Including software and program)
(2) The contents of this document are subject to change without notice.
(3) This manual is prepared with extreme care. However, if you have any question
or find any error or omission in writing, contact our dealer or JUKI Corporation.
(4) JUKI Corporation shall disclaim all the responsibility for any trouble resulting
from the user's abnormal operation regardless of Item (3).
(5) Microsoft, Windows are registered trademarks or trademarks of Microsoft
Corporation in the United States and /or other countries.
The company names and product names mentioned in this document are
generally registered trademarks or trademarks of the respective companies.
i
CAUTION
For the safe operation of machinery
All personnel engaged in the operation of the mounter and its accessories (here after referred to as "machines") including
the operators, service and maintenance personnel are required to read through this safety warning to make familiar with
its handling to prevent accidents and injuries.
This "Warning: For the safe operation of machinery" instructions contain aspects that are not included in the instruction
sheet attached to the product.
The following symbols are used throughout this instructions and on the product for the better understanding of various
warning labels. Please make yourself familiar with the contents and act accordingly.
1) Danger levels
DANGER
Parts of machinery the negligence or mishandling of which committed during the
operation, maintenance or other services on such parts will lead to severe accidents
involving serious personal injuries or even death.
WARNING
Parts of machinery the negligence or mishandling of which committed, or are left
unattended, during the operation, maintenance or other services on such parts may cause
potential danger to the personnel which may lead to injuries and/or even death.
CAUTION
Parts of machinery the negligence or mishandling of which committed, or are left
unattended, during the operation, maintenance or other services on such parts may cause
the medium-to-light level of hazards to the personnel involved.
2) Warning, prohibition and directive marks
Warning, prohibition and directives are marked with the following symbols:
Warning marks
Your hands or clothes may
get caught by the machines.
Beware of moving parts.
Contacts with them may
cause injuries.
Beware of movable parts.
Contacts with them may
cause injuries.
High voltage!!
Beware of electric shocks.
Beware of hot parts.
Contacts with them may
cause a burn.
If any load is imposed or you
lay your hand on the
machine, it may be damaged.
Direct eye contact with laser
light may result in serious
damage to the eye.
Prohibition marks
Directive symbols
If you touch the machine, you may be injured or
the machine may be damaged. Never touch
the machine.
It symbolizes a contact to a grounding wire.
It indicates the direction of turn.
Matters of Caution Regarding Safety
To prevent accidents due to electric shock, turn off power supply if it is necessary to open the electrical equipment
box. For added precaution, open the lid of the box only after a lapse of more than five minutes.
To turn off power supply means to turn off a power supply switch and then to
draw out a power plug from a receptacle or to separate the power cable from
the supply side. Hereinafter the same.
Situations in Which It Is Necessary to Turn Off Power Supply
1. In the case of an abnormality or an accident, or in the event of power failure,
immediately turn off power supply.
2. In order to prevent accidents due to unintended start-up of the machine, carry out inspection, repair, or
cleaning of the machine only after turning off power supply.
3. When drawing out the power supply plug, do it by holding the plug itself, not the cord.
DANGER
