Part 1 Basic Operation Chapter 1 Overview of the Machine

1-62

(2) Menu organization of the Program Editor screen

No.

Operation area

Sub menu

1 File

New

Open

Save

Save as

Save to file

Environment Setting

2 Edit

Replacement

Change component name

Update layers (All component)

Update layers (Current component)

Update pick offset

Mark copy

Mark paste

Mark database

Matrix Copy

Production program copy

3 Data

Data completion status

Data coherence check

4 Optimization

Optimization

Divided placement data

Nozzle layout

Component supply count

5 View

Feeder layout

All displays List Items

Select List Items

6 Machine operation

BOC mark

Area mark

Feeder bank mark (Front)

Feeder bank mark (Rear)

Place

Pick position

Pick height

7 Meas/Insp

Current component

All component

PWB Height

Vision Recognize

Coplanarity Inspection

Verify speed

Vision teaching

Bad mark teaching

Single Verification

Continuous Verification

8 Database

Call List

Collective recall

Part 1 Basic Operation Chapter 1 Overview of the Machine

1-63

(3) Menu organization of the production screen

No. Operation area Sub menu

1 File

Open

Save

Save as

Get and Save Machine Data

Save Management Info

Cont. prod. File Delete

2 Window

Prod Cond

Production status (Production condition)

Production status (Vision)

Production status (Operation condition)

Production status (Number of produced PWB)

Management Info (All)

Management Info (Head)

Management Info (Feeder)

Management Info (Pick)

Electric feeder check

Collation confirmation

3 Program

Retry list (Supplier)

Retry list (Not placed)

Component supply

Edit data

Program Check

Management Info is cleared.

4 Support

Plan support

Placement tracking

Verify Current check

Verify All check

GNRL. Vision direction single inspection

GNRL. Vision direction continuous inspection

Laser check

Auto-Correct pick position Clear

5 Tool

Operation option

Setting of displayed items

IFS server reconnect

6 Electric feeder check No submenu provided.

7 Cycle stop No submenu provided.

8 Feeder removal mode No submenu provided.

9 Feeder Bank Enable

Front bank valid

Rear bank valid

Part 1 Basic Operation Chapter 1 Overview of the Machine

1-64

(4) Menu organization of the Machine Setup screen

No.

Operation area

Sub menu

1 Device enable

Head

Base

Conveyor

MTC/MTS

VCS

2 Nozzle

Registered Nzl. no table

Read Nzl. data

ATC nozzle setup

Vacuum value without nozzle

Read ATC data *Available with an RS-1R only

ATC Setting *Available with an RS-1R only

3 Conveyor

PWB conveyor

Support table

Shape clamp position adjustment

4 Position setting

Component reject position

IC collection belt position

Head wait position

MTS position offset

MTC shuttle pick position

5 Function setting

Pick error conditions

Mark recognition speed

Solder print misalignment correction

Setting of feed to be performed immediately

Head height setting

Nozzle sliding fail check

Splicing setting

6 Unit setup

Signal light

Badmark reader threshold

Super Impose setting

Line connection

Coplanarity

Verification
