Part 1 Basic Operation Chapter3 Daily maintenance
3-33
1) Apply grease to the “Stopper Pin.”
Apply grease to the reception side (each elongate hole of the stoppers L and R of the stopper
brackets L and R) also.
Lubrication item
Conveyor stopper
Lubrication frequency:
Every two months
Tool to be used: Brush
Grease to be used:
6459 Grease N
Part 1 Basic Operation Chapter3 Daily maintenance
3-34
3.4 Consumable Parts List
No Part number Part name Q’ty Unit
When to
replace
(guidelin
e)
Remarks
(Year)
1
40046646
FILTER
8
Head
0.5
Filter without protrusions
2 E3052729000 FILTER 8 0.5
Filter equipped with
protrusions
3 40218794 FILTER 1 0.5
Filter exclusively
designed for an
electromagnetic valve
4
40183419
NOZZLE_ASSEMBLY_7509
－
0.9
No RFID tag (for RS-1)
5
40183420
NOZZLE_ASSEMBLY_7500
－
0.9
No RFID tag (for RS-1)
6
40183421
NOZZLE_ASSEMBLY_7501
－
0.9
No RFID tag (for RS-1)
7
40183422
NOZZLE_ASSEMBLY_7502
－
0.9
No RFID tag (for RS-1)
8
40183423
NOZZLE_ASSEMBLY_7503
－
0.9
No RFID tag (for RS-1)
9
40183424
NOZZLE_ASSEMBLY_7504
－
0.9
No RFID tag (for RS-1)
10
40183425
NOZZLE_ASSEMBLY_7505
－
1
No RFID tag (for RS-1)
11
40183426
NOZZLE_ASSEMBLY_7506
－
1
No RFID tag (for RS-1)
12
40183427
NOZZLE_ASSEMBLY_7507
－
1
No RFID tag (for RS-1)
13
40183428
NOZZLE_ASSEMBLY_7508
－
1
No RFID tag (for RS-1)
14
40183028
CONVEYOR_BELT_S
4
Conveyor
0.5
For input/output
15
40183030
CONVEYOR_BELT_C
4
0.5
For Center
16
40186617
CONVEYOR_BELT_S_150
(4)
0.5
Option for input/output
17
40186618
CONVEYOR_BELT_S_250
(4)
0.5
Option for input/output
18
40188357
CONVEYOR_BELT_S_ESD
4
0.5
Option for input/output
19
40188358
CONVEYOR_BELT_C_ESD
4
0.5
Option for Center
20
40188359
CONVEYOR_BELT_S_150_ESD
(4)
0.5
Option for input/output
21
40188360
CONVEYOR_BELT_S_250_ESD
(4)
0.5
Option for input/output
22 40113952 CONVEYOR_BELT_C_M 4 0.5
Option for input/output of
a machine for an
extra-large board
23 40073709 CONVEYOR_BELT_150 4 0.5
Option for the Center of a
machine for an extra-large
board
24 40215581 CONVEYOR_BELT_S_XL_ESD 4 0.5
Option for input/output of
a machine for an
extra-large board
25 40215582 CONVEYOR_BELT_C_XL_ESD 4 0.5
Option for center of a
machine for an extra-large
board
26 40183066 STOPPER_CHIP_650 1 -
Provided or not
depending on the board
material.
27 40128134 ADHESIVE_SHEET 250 FCS -
Replace this part every
time you use the machine.
28 40183167 FILTER 1
Feeder exchange
trolley
0.5
29 RO098240100 O-RING 2
Feeder exchange
trolley
-
30 40231037 SPONGE_ABRASIVE 1 Head -
Replace the head if it is
clogged with abrasive
grains.
Part 1 Basic Operation Chapter3 Daily maintenance
3-35
No Part number Part name Q’ty Unit
When to
replace
(guideline)
Remarks
(Year)
31 40189000 NOZZLE_ASSEMBLY_7500_CVS －
Head
0.9 No RFID tag (for RS-1)
32 40189001 NOZZLE_ASSEMBLY_7501_CVS － 0.9 No RFID tag (for RS-1)
33 40189002 NOZZLE_ASSEMBLY_7502_CVS － 0.9 No RFID tag (for RS-1)
34 40189003 NOZZLE_ASSEMBLY_7503_CVS － 0.9 No RFID tag (for RS-1)
35 40189004 NOZZLE_ASSEMBLY_7504_CVS － 0.9 No RFID tag (for RS-1)
36 40189005 NOZZLE_ASSEMBLY_7505_CVS － 0.9 No RFID tag (for RS-1)
37 40189006 NOZZLE_ASSEMBLY_7509_CVS － 0.9 No RFID tag (for RS-1)
38 40186979 NOZZLE_ASSEMBLY_7680 － 0.9 No RFID tag (for RS-1)
39 40222517 NOZZLE_ASSEMBLY_7509_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
40 40222518 NOZZLE_ASSEMBLY_7500_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
41 40222519 NOZZLE_ASSEMBLY_7501_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
42 40222520 NOZZLE_ASSEMBLY_7502_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
43 40222521 NOZZLE_ASSEMBLY_7503_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
44 40222522 NOZZLE_ASSEMBLY_7504_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
45 40222523 NOZZLE_ASSEMBLY_7505_RFID － 1
WITH RFID TAG
(for RS-1R) *1
46 40222524 NOZZLE_ASSEMBLY_7506_RFID － 1
WITH RFID TAG
(for RS-1R) *1
47 40222525 NOZZLE_ASSEMBLY_7507_RFID － 1
WITH RFID TAG
(for RS-1R) *1
48 40222526 NOZZLE_ASSEMBLY_7508_RFID － 1
WITH RFID TAG
(for RS-1R) *1
49 40222543 NOZZLE_ASSEMBLY_7500_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
50 40222544 NOZZLE_ASSEMBLY_7501_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
51 40222545 NOZZLE_ASSEMBLY_7502_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
52 40222546 NOZZLE_ASSEMBLY_7503_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
53 40222547 NOZZLE_ASSEMBLY_7504_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
54 40222548 NOZZLE_ASSEMBLY_7505_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
55 40222549 NOZZLE_ASSEMBLY_7509_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
56
40222542 NOZZLE_ASSEMBLY_7680_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
57
40223138
STYLUS_PEN
1(2)
Stylus
-
For RS-1R
58
40223139
LONG_KEYHOLDER
1(2) -
For RS-1R
*1 RFID tags are common to all RFID readers (whose destinations are Japan, Europe and the U.S.A.).
