Part 1 Basic Operation Chapter3 Daily maintenance
3-34
3.4 Consumable Parts List
No Part number Part name Q’ty Unit
When to
replace
(guidelin
e)
Remarks
(Year)
1
40046646
FILTER
8
Head
0.5
Filter without protrusions
2 E3052729000 FILTER 8 0.5
Filter equipped with
protrusions
3 40218794 FILTER 1 0.5
Filter exclusively
designed for an
electromagnetic valve
4
40183419
NOZZLE_ASSEMBLY_7509
－
0.9
No RFID tag (for RS-1)
5
40183420
NOZZLE_ASSEMBLY_7500
－
0.9
No RFID tag (for RS-1)
6
40183421
NOZZLE_ASSEMBLY_7501
－
0.9
No RFID tag (for RS-1)
7
40183422
NOZZLE_ASSEMBLY_7502
－
0.9
No RFID tag (for RS-1)
8
40183423
NOZZLE_ASSEMBLY_7503
－
0.9
No RFID tag (for RS-1)
9
40183424
NOZZLE_ASSEMBLY_7504
－
0.9
No RFID tag (for RS-1)
10
40183425
NOZZLE_ASSEMBLY_7505
－
1
No RFID tag (for RS-1)
11
40183426
NOZZLE_ASSEMBLY_7506
－
1
No RFID tag (for RS-1)
12
40183427
NOZZLE_ASSEMBLY_7507
－
1
No RFID tag (for RS-1)
13
40183428
NOZZLE_ASSEMBLY_7508
－
1
No RFID tag (for RS-1)
14
40183028
CONVEYOR_BELT_S
4
Conveyor
0.5
For input/output
15
40183030
CONVEYOR_BELT_C
4
0.5
For Center
16
40186617
CONVEYOR_BELT_S_150
(4)
0.5
Option for input/output
17
40186618
CONVEYOR_BELT_S_250
(4)
0.5
Option for input/output
18
40188357
CONVEYOR_BELT_S_ESD
4
0.5
Option for input/output
19
40188358
CONVEYOR_BELT_C_ESD
4
0.5
Option for Center
20
40188359
CONVEYOR_BELT_S_150_ESD
(4)
0.5
Option for input/output
21
40188360
CONVEYOR_BELT_S_250_ESD
(4)
0.5
Option for input/output
22 40113952 CONVEYOR_BELT_C_M 4 0.5
Option for input/output of
a machine for an
extra-large board
23 40073709 CONVEYOR_BELT_150 4 0.5
Option for the Center of a
machine for an extra-large
board
24 40215581 CONVEYOR_BELT_S_XL_ESD 4 0.5
Option for input/output of
a machine for an
extra-large board
25 40215582 CONVEYOR_BELT_C_XL_ESD 4 0.5
Option for center of a
machine for an extra-large
board
26 40183066 STOPPER_CHIP_650 1 -
Provided or not
depending on the board
material.
27 40128134 ADHESIVE_SHEET 250 FCS -
Replace this part every
time you use the machine.
28 40183167 FILTER 1
Feeder exchange
trolley
0.5
29 RO098240100 O-RING 2
Feeder exchange
trolley
-
30 40231037 SPONGE_ABRASIVE 1 Head -
Replace the head if it is
clogged with abrasive
grains.
Part 1 Basic Operation Chapter3 Daily maintenance
3-35
No Part number Part name Q’ty Unit
When to
replace
(guideline)
Remarks
(Year)
31 40189000 NOZZLE_ASSEMBLY_7500_CVS －
Head
0.9 No RFID tag (for RS-1)
32 40189001 NOZZLE_ASSEMBLY_7501_CVS － 0.9 No RFID tag (for RS-1)
33 40189002 NOZZLE_ASSEMBLY_7502_CVS － 0.9 No RFID tag (for RS-1)
34 40189003 NOZZLE_ASSEMBLY_7503_CVS － 0.9 No RFID tag (for RS-1)
35 40189004 NOZZLE_ASSEMBLY_7504_CVS － 0.9 No RFID tag (for RS-1)
36 40189005 NOZZLE_ASSEMBLY_7505_CVS － 0.9 No RFID tag (for RS-1)
37 40189006 NOZZLE_ASSEMBLY_7509_CVS － 0.9 No RFID tag (for RS-1)
38 40186979 NOZZLE_ASSEMBLY_7680 － 0.9 No RFID tag (for RS-1)
39 40222517 NOZZLE_ASSEMBLY_7509_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
40 40222518 NOZZLE_ASSEMBLY_7500_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
41 40222519 NOZZLE_ASSEMBLY_7501_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
42 40222520 NOZZLE_ASSEMBLY_7502_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
43 40222521 NOZZLE_ASSEMBLY_7503_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
44 40222522 NOZZLE_ASSEMBLY_7504_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
45 40222523 NOZZLE_ASSEMBLY_7505_RFID － 1
WITH RFID TAG
(for RS-1R) *1
46 40222524 NOZZLE_ASSEMBLY_7506_RFID － 1
WITH RFID TAG
(for RS-1R) *1
47 40222525 NOZZLE_ASSEMBLY_7507_RFID － 1
WITH RFID TAG
(for RS-1R) *1
48 40222526 NOZZLE_ASSEMBLY_7508_RFID － 1
WITH RFID TAG
(for RS-1R) *1
49 40222543 NOZZLE_ASSEMBLY_7500_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
50 40222544 NOZZLE_ASSEMBLY_7501_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
51 40222545 NOZZLE_ASSEMBLY_7502_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
52 40222546 NOZZLE_ASSEMBLY_7503_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
53 40222547 NOZZLE_ASSEMBLY_7504_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
54 40222548 NOZZLE_ASSEMBLY_7505_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
55 40222549 NOZZLE_ASSEMBLY_7509_CVS_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
56
40222542 NOZZLE_ASSEMBLY_7680_RFID － 0.9
WITH RFID TAG
(for RS-1R) *1
57
40223138
STYLUS_PEN
1(2)
Stylus
-
For RS-1R
58
40223139
LONG_KEYHOLDER
1(2) -
For RS-1R
*1 RFID tags are common to all RFID readers (whose destinations are Japan, Europe and the U.S.A.).
Part 1 Basic Operation Chapter3 Daily maintenance
3-36
3.5 Parts Recommended to Be Replaced on a Regular Basis
The components that have to be replaced on regular basis due to wear or degradation other than
expendables are shown in the table below.
Regardless of whether a device is described in the table below or not, all air devices have to be
replaced with new ones if oil or water is mixed into the air of them.
Contact our Service department or dealer for how to replace a component with a new one.
No. Part number Part name Quantity Device
When to
replace
(guideline)
(Year)
Remarks
1 PF901010000 FILTER ELEMENT 1 Cover 1
Pressure difference
between the front and
the rear: 0.1 MPa
2 PF901006000 FILTER ELEMENT B 1 Cover 1
Pressure difference
between the front and
the rear: 0.1 MPa
3 EZ175664711
BATTERY PACK
(BS06A-H24/2.5L)
1
Electric
section
3
4 40182492 UPPER_EDGE 1 Bank 1
5 40182493 LOWER_EDGE 2 Bank 1
6 40138045
VACUUM PUMP
MAINTENANCE KIT
1 Pump 0.9
* One year = 6,600 hours (22 hours/day × 300 days/year)
3.6 Used Grease and Oil
No Part No. Part name Capacity Remarks
1 MDFRX1001L0 DEFRIX OIL NO1 800ml
2 40032449 6459 GREASE N 400g A grease gun is used.
3 40127626 GREASE_GUN
4 40127627 GREASE_GUN_NOZZLE
5 40046643 CG2 GREASE 2.5mg Injector type
6 40094361 NSL GREASE 80g A hand grease pump is used
7 40098975 NSK_HGP
One-touch-mounting small
bellow-type container of grease
8 40106055 FLEXIBLE NOZZLE
For an XY ball screw that can be
attached onto a No. 6 grease gun
9 EZ764002555 AFF＋400 400g
