Part 2 Detailed Description of Each Function Chapter 12 Handling the Optional Devices
12-112
12.16.3 Flowchart
When you attach a nozzle on a head manually, follow the procedure below.
No.
Flowchart
Remarks
1
Refer to Chapter 8 “Machine Setup” of the
Instruction Manual.
2
Insert a nozzle until it is locked.
3
Refer to Chapter 2 “Production” of the
Instruction Manual
4
(See Section 4.4.1.)
5
Refer to Chapter 2 “Production” of the
Instruction Manual
6
Refer to Chapter 8 “Machine Setup” of the
Instruction Manual.
7
(See Section 4.4.2.)
8
Refer to Chapter 4 “Creating a Production
Program” of the Instruction Manual.
9
Refer to Chapter 2 “Production” of the
Instruction Manual
10
Refer to Chapter 2 “Production” of the
Instruction Manual
11
Refer to Chapter 2 “Production” of the
Instruction Manual
12
Perform inspections at the regular
intervals.
(Refer to Chapter 3 “Maintenance” of the
Instruction Manual.)
Manually attach a nozzle on a head.
Turn on the power.
Fix the adjacent heads.
Enable the manual nozzle attachment function.
Assign nozzles.
Load the nozzle data.
Create/edit a production program.
Daily inspection
Return to the origin.
Production
Finish the production.
Turn off the power.
Part 2 Detailed Description of Each Function Chapter 12 Handling the Optional Devices
12-113
When you attach a nozzle on a head manually for the second time and thereafter, follow the
procedure below.
No.
Flowchart
Remarks
1
Push the nozzle into the head until it is
locked.
2
Refer to Chapter 2 “Production” of the
Instruction Manual.
3
Refer to Chapter 2 “Production” of the
Instruction Manual.
4
Refer to Chapter 4 “Creating a Production
Program” of the Instruction Manual.
5
Refer to Chapter 2 “Production” of the
Instruction Manual.
6
Refer to Chapter 2 “Production” of the
Instruction Manual.
7
Refer to Chapter 2 “Production” of the
Instruction Manual.
8
Perform inspections at the regular
intervals.
(Refer to Chapter 3 “Maintenance” of the
Instruction Manual.)
Finish the production.
Turn off the power.
Create/edit a production program.
Check the manual nozzle attachment condition.
Turn on the power.
Production
Daily inspection
Return to the origin.
Part 2 Detailed Description of Each Function Chapter 12 Handling the Optional Devices
12-114
To reset Manual nozzle attachment mode to Production mode with using the ATC, follow the
procedure below.
No.
Flowchart
Remarks
1
Refer to Chapter 8 “Machine Setup” of the
Instruction Manual.
2
3
Refer to Chapter 2 “Production” of the
Instruction Manual.
4
(See Section 4.4.1.)
5
Refer to Chapter 2 “Production” of the
Instruction Manual.
6
Refer to Chapter 8 “Machine Setup” of the
Instruction Manual.
7
Refer to Chapter 4 “Creating a Production
Program” of the Instruction Manual.
8
Refer to Chapter 2 “Production” of the
Instruction Manual.
9
Refer to Chapter 2 “Production” of the
Instruction Manual.
10
Refer to Chapter 2 “Production” of the
Instruction Manual.
11
Perform inspections at the regular
intervals.
(Refer to Chapter 3 “Maintenance” of the
Instruction Manual.)
Daily inspection
Disable the manual nozzle attachment function.
Release the fixed adjacent heads.
Assign nozzles.
Remove the nozzle manually attached on the head.
Turn on the power.
Return to the origin.
Production
Finish the production.
Turn off the power.
Create/edit a production program.
