Part 1 Basic Operation Chapter 2 Production
2-84
8) Error (Detail – MTS)
No.
Displayed error message
1
Command error
2
Parameter error
3
READY time out
4
ETX time out
5
Sync char time out
6
Response time out
7
Data error
8
Rspns error
9
Request at offline
10
Stacker Lock
11
Could not detect tray
12
Cover open
13
Supply
14
No Stacker
15
Door open
16
Component remain
17
Receive pick finish during shuttle transporting
18
MS parameter not entered
19
Request Changing Stacker when Normal Mode
20
Home position error(Z)
21
Home position error(Y)
22
Shutter close error
23
Shutter open error
24
Emergency stop
25
Over run error(Z + limit)
26
Over run error(Y + limit)
27
Y Holder Error
28
Not finish initialize
29
Mounter emergency stop
30
Over run eror(Z - limit)
31
Over run eror(Y - limit)
32
Interlock error
33
Z error
34
Y error
35
Opening Y Holder when Z Axis Moving
36
Door,Cover SW
37
Overrun error
38
Z axis sensor error
39
Y axis sensor error
40
Clamping Stacker Error
41
RAM error
42
Illegal break current
43
Holder Sensor error
44
Sensor error(Z + limit)
45
Sensor error(Y + limit)
46
Changing Stacker Error
47
NV-RAM error
48
Close/open sensor error
49
Drive Time Out(Z)
50
Driver Alarm(Y)
51
Escape Error(Y)
Part 1 Basic Operation Chapter 2 Production
2-85
No.
Displayed error message
52
Tray Error.
53
Detect Compo Floating
54
Clamping Stacker Error
55
Impossible servo driver on(Z)
56
Servo alarm
57
Test Mode Moving Time Out
58
Request cancel
59
Switch Off-line
60
Switch Supply
61
Press MTC EMG Sw
62
Retry Out
63
Empty Parts
64
Supply
65
MTC COMM ERR (Data Error)
66
MTC COMM ERR (Communication Error)
67
MTC COMM ERR (Procedure Error)
68
MTC COMM ERR (Synchronous Error)
69
MTC COMM ERR (Power Off)
70
Step Number of Tray is Wrong
71
MTC is not Available in Setup Data
72
Not Finding STX ETX
73
Undefined Command Code is Specified
74
Parts Request Send Multiplexy (WAIT)
75
Parts Request Send Multiplexy (KICK)
76
Parts Request is Abnormal
77
Response Time Out
78
MTC Initialize Incompletely
79
Unmovable by Off-line
80
Unmovable by Air-Down
81
IPC Object Open Error (MTS-1)
82
IPC Object Open Error (MTS-2)
83
IPC Object Close Error (MTS-1)
84
IPC Object Close Error (MTS-2)
85
IPC Send Error (MTS-1)
86
IPC Receive Error (MTS-1)
87
IPC Send Error (MTS-2)
88
IPC Receive Error (MTS-2)
89
Move error
90
Retry over
91
No component
92
Offline
93
Supply
94
Time Out (Ready Waiting Observation 10sec)
95
Time Out (Sync Character Observation 4sec)
96
Time Out (ETX Observation 3sec)
97
MTC Power Off
98
Time Out (Responseless Observation 60sec)
99
Receive Data Validity Error
100
Ring Buffer Access Error
101
Time Out (Data Link Release 1)
102
Time Out (Data Link Release 2)
103
MTC Communication Initialize Failed
Part 1 Basic Operation Chapter 2 Production
2-86
9) Error (Detail – MTC)
No.
Displayed error message
1 Command error
2 Parameter error
3 No component
4 READY time out
5 ETX time out
6 Sync char time out
7 Response time out
8 Data error
9 Rspns error
10 Request at offline
11 Stacker Lock
12 Picking error(head)
13 Picking error(shuttle)
14 Not recovery component
15 Could not detect tray
16 Cover open
17 Transport error(head)
18 Transport error(shuttle)
19 Supply
20 No Stacker
21 Door open
22 Component remain
23 BGA Holder Error
24 Detecting Board on the Conveyor
25 Receive pick finish during shuttle transporting
26 Head Vacuum No.1 Sensor
27 Shuttle Vacuum No.1 Sensor
28 Failed to detect Origin Auto PWB Conveyor
29 Teaching spot turned off
30 MS parameter not entered
31 Head Vacuum No.2 Sensor
32 Shuttle Vacuum No.2 Sensor
33 Detecting Motor Error Auto PWB conveyor
34 Home position error(Z)
35 Home position error(X)
36 Home position error(Y)
37 No.1 Head Error
38 Shuttle error
39 Shutter close error
40 Shutter open error
41 Emergency stop
42 Over run error(Z + limit)
43 Over run error(X + limit)
44 Over run error(Y + limit)
