Part 1 B asic O peration Part 1 Basic Oper ation Chapter 1 Overv ie w of the Machine .................................. 1-1 Chapter 2 Production ........................................................ 2-1 Chapter 3 Dail…
12.15 Tape set unit (applicable in and after Rev. D)................................................................... 12-108
12.16 Manual Nozzle Attachment Function .................................................................................... 12-110
12.17 Individual Nozzle Management System (RFID) .................................................................. 12-126
12.18 R-ATC Plate ............................................................................................................................. 12-133
12.19 Gripper Nozzle ......................................................................................................................... 12-134
Chapter 13 Supplementary Information for Creating a Production Program .......................... 13-1
Examples of component dimensions .......................................................................................... 13-1
Managing the Control Data .......................................................................................................... 13-9
Functions available to each user level ..................................................................................... 13-17
File type of Production Programs.............................................................................................. 13-18
Patterns which can be registered as the user defined template ......................................... 13-19
Laser status list ............................................................................................................................ 13-20
Log tool ......................................................................................................................................... 13-21
Appendix
Glossary ...................................................................................................................................................... A-1
Part 1 Basic Operation
Part 1 Basic Operation
Chapter 1 Overview of the Machine .................................. 1-1
Chapter 2 Production ........................................................ 2-1
Chapter 3 Daily maintenance ............................................ 3-1
Chapter 4 Creating a Production Program ........................ 4-1
Chapter 5 Database .......................................................... 5-1
Part 1 Basic Operation Chapter 1 Overview of the Machine
1-1
Overview of the Machine
General
Introduction
The RS-1 Series is a multiple-head type general-purpose mounter that constitutes the core of the
next-generation flex modular line, and its safety, reliability, serviceability and economic efficiency are
increased further, while it inherits the flexibility performance under the modular concepts that have
been built up until now.
Use of a newly developed parallel 8-nozzle head with the up/down integrated drive function
supports 1-head solution that can place components ranging from 0.25 × 0.125 mm extremely small
components to 50 × 150 mm large components without changing the head.
As the RF feeder is used together, a placement tact of 42,000 CPH (47,000 CPH in case of an
RS-1R) is achieved under the optimal conditions. Additionally, as a high power rotation motor is
equipped as standard, components with a size of 50 mm x 150 mm that have a large moment of
inertia can also be placed.
Additionally, as the newly developed 8-nozzle head described previously covers a placement area
of up to 650 mm of the movement stroke, one clamp with 650 mm × 370 mm, twice clamp at 950
mm × 370 mm, Furthermore, by combining transport extension, it is possible to mount on a PWB
with a size of up to 1200 mm × 370 mm. An RS-1XL can mount components on a board whose size
is up to 650 mm×560 mm.
Furthermore, a combination of this machine and floor productivity improvement support system
allows you to comprehensively manage and optimize various tasks and information related to
productions performed with mounters per floor (that is, production site). This helps you to improve
the productivity and manufacturing quality, and reduce the cost by enhancing the efficiency.
* For the detailed functions of floor productivity improvement support system, refer to " Each
system instruction manual"
